At a glance
Instrument cluster
Item Page
1 L Left turn signal indi-
cator lamp
2 v Antilock Brake Sys-
tem (ABS)/Electronic
Stability Program
(ESP) warning lamp
313
3 Speedometer
4 Multifunction display
with:
ț Basic display with out-
side temperature display 146
ț Status indicator with
malfunction warning
message
ț Trip odometer 132
5 l Distance warning
lamp 1
1 Vehicles without Distronic*: Warning lamp without
function. It illuminates with the ignition on. It should
go out when the engine is running.
317
6 K Right turn signal indi-
cator lamp
Item Page
7 Coolant temperature dis-
play with:
• Coolant tempera-
ture warning lamp
316
8 Tachometer with:
1 Supplemental
restraint system
indicator lamp
318
- Antilock Brake Sys-
tem (ABS) malfunc-
tion indicator lamp
312
< Seat belt telltale 317
A High beam head-
lamp indicator
127
9 Main odometer with:
ț Selector lever position 43
ț Program mode 168
Item Page
a Clock with: 148
; Brake warning
lamp, except
Canada
314
3 Brake warning
lamp, Canada only
314
? Engine malfunction
indicator lamp
315
b Fuel display with:
A Fuel reserve warn-
ing lamp
317
c Reset button for:
ț Resetting trip
odometer 132
ț Adjusting instrument
cluster illumination 131
ț Confirming new time
settings 148
