4
9) Menu setting commands
(Not executable in stand-by mode. Possible only to read during muting.)
The menu setting commands are used for the menu setting of this projector. If the personal computer sends the
command without attaching the data code, the projector attaches to the received command its current setting
value as the data code and send it back to the PC.
ITEM ASCII HEX VALUE
GAMMA MODE GS 47h 53h 0 (SPORTS), 1 (VIDEO), 2 (CINEMA), 3 (USER1),
4 (USER2), 5 (AUTO)
GAMMA MODE-USER1 GSU1 47h 53h 55h 31h +0 (SPORTS), +1 (VIDEO), +2 (CINEMA),
±05 ±05 ±05 (HIGH, MID, LOW)
GAMMA MODE-USER2 GSU2 47h 53h 55h 32h +0 (SPORTS), +1 (VIDEO), +2 (CINEMA),
±05 ±05 ±05 (HIGH, MID, LOW)
CONTRAST PP 50h 50h ±30
BRIGHTNESS QQ 51h 51h ±30
COLOR TEMP. A 41h 1 (COOL), 2 (MIDIUM), 3 (WARM), 4 (USER),
5 (HIGH BRIGHTNESS)
COLOR TEMP.-USER
(CONTRAST) P 50h ±30 ±30 ±30 (R, G, B)
COLOR TEMP.-USER
(BRIGHTNESS) Q 51h ±30 ±30 ±30 (R, G, B)
COLOR T 54h ±10
TINT S 53h ±10
SHARPNESS R 52h ±05
BrilliantColor TM WEH 57h 45h 48h 0–10
VERTICAL LOCATION IMP 49h 4Dh 50h ±26
LAMP MODE LM 4Ch 4Dh 0 (STANDARD), 1 (LOW)
AUTO POWER ON APON 41h 50h 4Fh 4Eh 0 (OFF), 1 (ON)
AUTO POWER OFF APOF 41h 50h 4Fh 46h 00 (OFF), 05, 10, 15, 30, 60
SPLASH SCREEN SS 53h 53h 0 (OFF), 1 (ON)
BACK COLOR BB 42h 42h 0 (BLACK), 1 (BLUE)
IMAGE REVERSE IR 49h 52h 0 (OFF), 1 (MIRROR), 2 (INVERT), 3 (MIRROR INVERT)
TRIGGER OUT SCT 53h 43h 54h 0 (OFF), 1 (ON)
TEST PATTERN TP 54h 50h 0 (OFF), 1 (CROSS HATCH)
ASPECT SC 53h 43h 0 (AUTO), 1 (4:3), 2 (16:9), 3 (ZOOM1), 4 (ZOOM2),
5 (STRETCH), 6 (REAL)
PASSWORD FUNCTION PSLOCK 50h 53h 4Ch 4Fh 43h
4Bh 0**** (UNLOCK), 1**** (DISPLAY INPUT),
2**** (MENU ACCESS)
****is a 4-digit figure (password).
MENU POSITION MP 4Dh 50h 0 (Upper left), 1 (Lower right)
CINEMA MODE CINE 43h 49h 4Eh 45h 0 (OFF), 1 (AUTO)
VIDEO SIGNAL
(VIDEO only) VS 56h 53h 0 (AUTO), 1 (NTSC), 2 (PAL), 3 (SECAM), 4 (4.43NTSC),
5 (PAL-M), 6 (PAL-N), 7 (PAL-60)
SET UP STU 53h 54h 55h 0 (AUTO), 1 (OFF), 2 (3.75%), 3 (7.5%)
SCART INPUT SRT 53h 52h 54h 0 (OFF), 1 (ON)
LANGUAGE LG 4Ch 47h 0 ( ), 1 (English), 2 (Español), 3 (Deutsch), 4 (Français),
5 (Italiano), 6 ( ), 7 ( ), 8 ( ), 9 (PORTUGUÊS)
RESET ALL RSTALL 52h 53h 54h 41h 4Ch 4Ch
HORIZ.POSITION HP 48h 50h +: increment, -: decrement *1
VERT.POSITION VP 56h 50h +: increment, -: decrement *1
FINE SYNC. FN 46h 4Eh 00–31
TRACKING TRK 54h 52h 4Bh +: increment, -: decrement *1
COMPUTER INPUT CIN 43h 49h 4Eh 0 (RGB), 1 (YC
B
C
R
/YP
B
P
R
), 2 (AUTO)
OVER SCAN VOS 56h 4Fh 53h 00–10
HOLD HLD 48h 4Ch 44h 0 (OFF), 1 (ON)
HOLD BEGIN HLB 48h 4Ch 42h 00–99
HOLD END HLE 48h 4Ch 45h 00–99
CLAMP POSITION CLP 43h 4Ch 50h 001–255
CLAMP WIDTH CLW 43h 4Ch 57h 01–63
VERT.SYNC. VSC 56h 53h 43h 0 (AUTO), 1 (OFF)
LPF LPF 4Ch 50h 46h 0 (OFF), 1 (ON)
SHUTTER(U) SHU 53h 48h 55h 00–32
SHUTTER(L) SHL 53h 48h 4Ch 00–32
SHUTTER(LS) SHLS 53h 48h 4Ch 53h 00–95
SHUTTER(RS) SHRS 53h 48h 52h 53h 00–95
