3
6) Remote commands
(Not executable in stand-by mode. When the remote commands are sent while the
splash screen is being displayed, the splash screen is only canceled.)
Some remote control operations can be achieved by the remote command codes. The remote commands have no
data codes.
Button’s name on remote ASCII HEX Button’s name on remote ASCII HEX
r53 72h 35h 33h AV MEMORY 1 re4 72h 65h 34h
r2b 72h 32h 62h AV MEMORY 2 re5 72h 65h 35h
r4f 72h 34h 66h AV MEMORY 3 re6 72h 65h 36h
r59 72h 35h 39h CONTRAST rd0 72h 64h 30h
MENU r54 72h 35h 34h BRIGHTNESS rd1 72h 64h 31h
ENTER r10 72h 31h 30h COLOR TEMP. rd4 72h 64h 34h
AUTO POSITION r09 72h 30h 39h GAMMA rd5 72h 64h 35h
ASPECT re2 72h 65h 32h SHARPNESS rd6 72h 64h 36h
BLANK ra6 72h 61h 36h KEYSTONE r43 72h 34h 33h
[Example] When displaying the MENU selection bar. (Figures and symbols enclosed in quotation marks are
ASCII codes.):
Sending commands
from the PC, etc.
Status code
from the projector
Description
30 30 72 35 34 0D
‘0’ ‘0’ ‘r’ ‘5’ ‘4’ ‘ ’ Command operating the same as the
MENU button
30 30 72 35 34 0D
‘0’ ‘0’ ‘r’ ‘5’ ‘4’ ‘ ’ Command receipt confirmation
(Command echo back)
7) Password lock commands
The password lock commands control the password lock. The password lock enabling or disabling command is
sent with a 4-digit figure (password) added to the end of the data code. When the password lock is enabled or
disabled successfully, the projector sends a return command comprising the data code, password, and “1” at the
end. When enabling or disabling the password lock fails, it sends a return command with “0” at the end. There is
no reconfirmation of the password.
ITEM ASCII HEX VALUE
Password lock enabling/
disabling PSLOCK 50h 53h 4Ch 4Fh 43h 4Bh 0**** (Disabling), 1**** (DISPLAY INPUT),
2**** (MENU ACCESS)
**** is a 4-digit figure (password).
8) Reading command diagram
The projectors operating status, such as POWER-ON/OFF and the currently selected input terminal, etc. can be monitored.
ASCII HEX
Function Data (Receive) Function Data (Receive)
POWER ON vP 1 76h 50h 31h
POWER OFF vP 0 76h 50h 30h
INPUT COMPUTER vI r1 76h 49h 72h 31h
INPUT COMPONENT vI c1 76h 49h 63h 31h
INPUT HDMI vI d1 76h 49h 64h 31h
INPUT VIDEO vI v1 76h 49h 76h 31h
INPUT S-VIDEO vI v2 76h 49h 76h 32h
POWER ON/OFF INPOSSIBLE vPK 0 76h 50h 4Bh 30h
POWER ON/OFF POSSIBLE vPK 1 76h 50h 4Bh 31h
NO SIGNAL SUPPLIED vSM 0 76h 53h 4Dh 30h
SIGNAL SUPPLIED vSM 1 76h 53h 4Dh 31h
The PC sends the command without attaching the data code to it. On the other hand, the projector attaches to the
received command its current operating status as the data code and send it back to the PC.
[Example] When checking the currently selected input terminal (when the INPUT VIDEO is being selected). (Figures
and symbols enclosed in quotation marks are ASCII codes.):
Sending commands
from the PC, etc.
Status code
from the projector
Description
30 30 76 49 0D
‘0’ ‘0’ ‘v’ ‘I’ ‘ ’ Command for checking the input
terminal
30 30 76 49 76 31 0D
‘0’ ‘0’ ‘v’ ‘I’ ‘v’ ‘1’ ‘ ’ Check result (VIDEO)
