MITSUBISHI ELECTRIC MultiSync LCD1920NX User Manual

Page 10

English-8

LANGUAGE: Selecting preferred language used in the OSD menus. Under Main Menu, scroll to Language using [+] or

[–] button, then press [MENU] button to activate the function. Press [+] or [–] button to choose preferred Language,

then press [MENU] to return to Main Menu.

MAIN MENU:

Returning to OSD main menu. Press [+] or [–] button to select MAIN MENU, then press [MENU]

button to return to OSD Main Menu.

MISC Sub-Menu

Under the Main Menu, select MISC using the [+] or [–] button, then press [MENU] button to enter MISC Sub-Menu.

RESOLUTION NOTIFIER:

This optimal resolution is 1280 x 1024. If ON is selected, a message will appear on

the screen after 30 seconds, notifying you that the resolution is not at 1280 x 1024.

H-OSD POSITION:

Moving the OSD position on the screen to the right or left. Select H-OSD POSITION using

[+] or [–] button, then press [MENU] button to activate the function. Press the [+] button to move the OSD

position to the right, [–] button to move left. Then press [MENU] to return to MISC Sub-Menu.

V-OSD POSITION:

Moving the OSD position on the screen up or down. Select V-OSD POSITION using [+] or

[–] button, then press [MENU] button to activate the function. Press the [+] button to move the OSD position up,

[–] button to move down. Then press [MENU] to return to MISC Sub-Menu.

SMOOTHING:

Making the displayed texts smooth. Select SMOOTHING using [+] or [–] button, then press

[MENU] button to activate the function. Press [+] or [–] button and adjust to your liking. Press [MENU] button

to return to MISC Sub-Menu.

INVISIBLE:

Activating the OSD background to be invisible. Select INVISIBLE using the [+] or [–] button, then

press [MENU] button to select either On or Off option.

INFORMATION:

Displaying the timing mode (video signal input) coming from the graphics card in the computer.

Select INFORMATION using the [+] or [–] button, then press [MENU] to display the mode. Then press [MENU]

button to return to MISC Sub-Menu.

RECALL:

Returning the adjustments back to factory settings if the monitor is not operating at its original factory

settings. Select RECALL using the [+ or [–] button, then press [MENU] button to reset the settings.

MAIN MENU:

Returning to OSD main menu. Press [+] or [–] button to select MAIN MENU, then press [MENU]

button to return to OSD Main Menu.

EXIT:

Turning off the OSD. Select EXIT using the [+] or [–] button, then press [MENU] to exit the OSD.

OSD Warning

NO SIGNAL:

This function gives a warning when there is no signal present. After power is turned on or when there is

a change of input signal or video is inactive, the

No Signal

window will appear.

RESOLUTION NOTIFIER:

This function gives a warning of use with optimized resolution. After power is turned on or

when there is a change of input signal or the video signal doesn’t have proper resolution, the

Resolution Notifier

window will open. This function can be disabled in the MISC Sub-Menu.

OUT OF RANGE:

This function gives a recommendation of the optimized resolution and refresh rate. After the power is

turned on or there is a change of input signal or the video signal doesn’t have proper timing, the

Out Of Range

will appear.
