Model 553 – MTD 31AH553G401 User Manual
Page 26
26
Model 553
Ref. No.
Part No.
Description
1.
684-0008A
Shift Arm Assembly
2.
710-0262
Carriage Bolt 5/16-18 x 1.5”
3.
710-0449
Carriage Bolt 5/16-18 x 2.25”
4.
710-0788
TT Screw 1/4-20 x 1”
5.
710-0837
Oval C-Sk. Screw AB #10-16 x
0.625”
6.
710-0890A
Shear Bolt 5/16-18 x 1.5”
7.
710-3008
Hex Screw 5/16-18 x .75”
8.
711-0677
Ferrule
9.
712-0429
Hex Lock Nut 5/16-18
10.
712-3010
Hex Nut 5/16-18
11.
714-0104
Cotter Pin
12.
720-0284
Handle Knob
13.
725-1757
Heated Grip
14.
736-0242
Belleville Washer
15.
736-0275
Flat Washer
16.
736-0451
Saddle Washer
17.
747-0620A
Shift Rod: Upper
18.
747-0621
Shift Rod: Lower
19.
749-0951
Lower Handle
20.
749-0952A
Upper Handle: L Style RH
21.
749-0953A
Upper Handle: L Style LH
22.
750-0963
Connector: Shift Rod
23.
618-0419
Gear Assembly: Ring
24.
629-0937
Electric Harness: Lower
25.
710-0262
Carriage Bolt: 5/16-18 x 1.5”
26.
710-0451
Carriage Bolt: 5/16-18 x .75”
27.
710-0599
TT Screw: 1/4-20 x 0.5”
28.
710-0602
TT Screw: 5/16-18 x 1”
29.
710-0805
Hex Screw: 5/16-18 x 1.5”
30.
710-0817
TT Screw: 5/16-18 x 1.25”
31.
710-0896
Hex Screw AB: 1/4-14 x 0.625”
32.
710-3008
Hex Scew: 5/16-18 x .75”
35.
712-3027
Hex Flange Lock Nut
36.
724-0249
Electric Motor: Chute Crank
37.
725-0157
Cable Tie
38.
731-0851A
Chute Flange Keeper
39.
731-1300A
Lower Chute
40.
731-1313C
Cable Guide: Chute Tilt
41.
731-1320
Upper Chute
42.
731-2279
Motor Cover: Chute Rotation
43.
736-0159
5/16 Washer
44.
736-0242
Belleville Washer
45.
736-0506
Special Washer
46.
746-0896
Control Cable
47.
746-0901
Control Cable
48.
750-1232
Spacer
49.
782-0599
Motor Bracket
50.
784-5594
Cable Bracket
51.
784-5604
Handle: Chute Tilt
52.
629-0936
Harness Assembly: Upper
53.
684-0036
Handle Assembly RH:
Engagement, Black
54.
684-0037
Handle Assembly LH:
Engagement, Black
55.
710-1003
Special Hex Screw
56.
712-0271
Hex Sems Nut: 1/4-20
57.
712-0693
Hex Nut
58.
716-0398
Lock Ring: Toggle Switch
59.
720-0232
Shift Knob
60.
725-1672
Lamp Housing
61.
725-1755
Toggle Switch: Double Throw
62.
725-1756
Toggle Switch: Single Throw
63.
725-1759
Halogen Lamp: 50W, 12V
64.
726-0152
Mounting Clamp
65.
731-2275
Handle Panel
66.
736-0226
Flat Washer
67.
747-1136
Headlight Retainer
Ref. No.
Part No.
Description
