Microstar G41M User Manual
Page 49
3-13
BIOS Setup
On-Chip IDE Controller
These items allow users to enable or disable the IDE controller.
PCI IDE BusMaster
This item allows you to enable/ disable BIOS to used PCI busmastering for
reading/ writing to IDE drives.
On-Chip SATA Controller
These items allow users to enable or disable the SATA controller.
RAID Mode
This item is used to enable/disable the RAID function for SATA devices.
I/O Device Configuration
Press
COM Port 1/2
Select an address and corresponding interrupt for the first serial port.
Parallel Port
There is a built-in parallel port on the on-board Super I/O chipset that provides
Standard, ECP, and EPP features. It has the following options:
[Disabled]
[3BC]
Line Printer port 0
[278]
Line Printer port 2
[378]
Line Printer port 1
Parallel Port Mode
This item allows you to select the parallel port mode.
