Maxtor’s DiamondMax
Plus 40 series delivers
outstanding performance
including:

• 7,200 RPM spin speed

• 10.2 GB of storage per disk

• < 9.0 ms average seek

• 2 MB cache buffer

• Fast data transfer rates

(up to 66 MB/sec)

• 3-year warranty

E R F O R M A N C E

P E C I F I C A T I O N S

Seek Times (typical)

Track to Track

1 ms

Average

< 9.0 ms

Maximum

< 20 ms

Average Latency

4.17 ms

Rotation Speed (± 0.1%)

7,200 RPM

Controller Overhead

< 0.3 ms

Start Time (0 - drive ready)

< 10 sec typical

ATA

R A N S F E R

AT E S

To/From Interface

up to 66.7 MB/sec

To/From Media

up to 43.2 MB/sec

R I V E

O N F I G U R A T I O N

Integrated Controller

ATA-5/UDMA 66

Buffer Size

2 MB

Buffer Type

SDRAM

Data Zones per Surface

Bytes per Sector/Block

512

E L I A B I L I T Y

P E C I F I C A T I O N S

Start/Stop Cycles

50,000 (minimum)

Component Design Life

5 years (minimum)

Data Errors (non-recoverable)

< 1 per 10

bits read

Annual Return Rate (ARR)

<1%

O W E R

E Q U I R E M E N T S

(

T Y P I C A L

)

O D E

1 2 V ± 1 0 %

5 V ± 5 %

O W E R

Spin-up (peak)

2500 mA

620 mA

Seek

800 mA

510 mA

12.9 W

Read/Write

350 mA

530 mA

6.8 W

Idle

350 mA

490 mA

6.6 W

Standby

15 mA

235 mA

1.4 W

N V I R O N M E N T A L

I M I T S

C O U S T I C S

Idle mode

3.6 bel (average sound power)

E M P E R AT U R E

Operating

5° C - 55° C

Non-operating, Storage

-40° C - 71° C

E L AT I V E

U M I D I T Y

(

N O N

C O N D E N S I N G

)

Operating, Non-operating, Storage

5% - 95%

Maximum Wet Bulb

30° C

LT I T U D E

(

R E L AT I V E T O S E A L E V E L

)

Operating

-200 - 10,000 feet

Non-operating

-200 - 40,000 feet

I B R AT I O N

Operating, random, no errors

10 - 45 Hz at 0.004 G2/Hz
48 - 62 Hz at 0.008 G2/Hz

65 - 300 Hz at 0.004 G2/Hz

301 - 500 Hz at 0.0006 G2/Hz

Non-operating, random

10 - 2,000 Hz at 4.1 Grms, no damage

Operating, swept sine (1 octave per minute)
5 - 20 Hz

0.049” double amplitude

21 - 300 Hz

1.0 G peak amplitude

H O C K

Operating Mechanical Shock

30 Gs, 2 ms, no errors

Non-operating Mechanical Shock

250 Gs, 2 ms, no damage

H Y S I C A L

I M E N S I O N S

Height

1.02 in

2.59 cm

Length

5.77 in

14.66 cm

Width

4.02 in

10.21 cm

Weight

1.30 lbs

0.59 kg

All Maxtor products are backed by the

No Quibble

service policy, the benchmark

for service and support in the industry.

No Quibble includes:

• Advance replacement in 2 business days

• MaxFax

24-hour automated technical support

• Maxtor’s commitment to total customer satisfaction

• Phone technicians available Monday– Friday

For more information or to talk to a customer support representative, call: (U.S. and Canada)
800-2MAXTOR. Available 5

.– 5

. (PT) Mon – Fri; (Europe) +353 1 204 1111. Available

9:30

.– 6

. (CET) Mon –Thurs and 9:30

.– 5

. (CET) Fri; (Asia/Pacific) 800-481-6788.

Available 8

.– 5:30

. (GMT+8) Mon – Fri; or visit our homepage on the Internet at

http://www.maxtor.com.

Based on 1- and 2-disk models;

Without non-recoverable errors. Specifications subject to change without notice. Maxtor defines

1 megabyte as 10

or 1 million bytes and 1 gigabyte as 10

or 1 billion bytes. DualWave

, MaxFax

, MaxSafe

and ShockBlock

are trademarks of Maxtor. DiamondMax

, Maxtor

and No Quibble

are registered trademarks of Maxtor Corporation. Printed in the

MODEL

54098U8

53073U6

52049U4

51536U3

51024U2

CAPACITY

40,981 MB

30,735 MB

20,490 MB

15,367 MB

10,245 MB

HEADS

DISKS
