Tongs and Tips
(Must be ordered separately from spot welders. One pair of tips are supplied with each set of tongs.)
Standard 90°
No. 1 Morse Taper
No. 2 Morse Taper
#040 218
—
#040 219
—
#040 220
#041 001
6 in.
(150 mm)
12 in.
(304 mm)
18 in.
(457 mm)
Tong Length
Tongs
6-1/4 in.
(159 mm)
4-1/4 in.
(108 mm)
7-1/2 in.
(190 mm)
9 in.
(229 mm)
X
#040 223
#040 308
Standard 45°
No. 1 Morse Taper
No. 2 Morse Taper
—
—
#041 004
—
#041 005
#040 296
#040 851
#040 225
TT-6W
No. 2 Morse Taper
TT-9W
No. 2 Morse Taper
—
—
#041 838
#040 308
—
—
#041 840
#040 308
Tips Included
4-1/4 in.
(108 mm)
6-1/4 in.
(159 mm)
X
Notes for tongs and tips:
Tongs and tips shown to the left
can be used with all PSW and
SSW model spot welders.
Recommended maximum tong
length is 18 inches (457 mm).
Tong throat-height dimen sion
for standard 90° and 45° tongs
is 4-1/4 inches (108 mm).
Throat length is measured from
the center of the spot tips to the
front water hose connection.
X = tong length.
One set of tips is supplied with
each set of tongs.
Tips are made of RWMA
Class 2 alloy.
Maximum welding capabilities
are obtained with minimum
tong length.
MT = Morse Taper.
No. 1 Morse Taper has smaller
diameter than No. 2 Morse
Taper.
No. 1 MT (Pointed)
#040 223
No. 1 MT (Offset)
#040 224
No. 1 MT (Offset)
#040 851
No. 1 MT (Offset)
#040 226
No. 1 MT (Offset)
#040 298
No. 2 MT (Pointed)
#040 308
No. 2 MT (Offset)
#040 225
No. 1 MT (Flat Swivel Tip)
Matching Pointed Tip
#040 216
Adapter (adapts No. 1 Morse Taper Tip
to No. 2 receptacle)
#040 227
2 tips
2 tips
2 tips
2 adapters
2 tips
2 tips
2 tips
2 tips
2 tips
Quantity
Tips
Standard No. 1 Tongs, 90°
Standard No. 1 Tongs, 90°
Standard No. 1 Tongs, 45°
Standard No. 2 Tongs, 45°
Standard No. 1 Tongs, 90°
Standard No. 1 Tongs, 90°
Standard No. 1 Tongs, 90°
Standard No. 2 Tongs, 90°
TT-6W Tongs
TT-9W Tongs
Standard No. 2 Tongs, 90°
TT-6W Tongs (top)
TT-9W Tongs (top)
Where Used
