19.00" (483mm)
ventilation slots
(do not cover)
17.24" (438mm)
De
pt
h
15
.6
5"
(3
98
m
m
)
N
OT
E:
T
he
D
ep
th
is
m
ea
su
re
d
fr
om
t
he
re
ar
fa
ce
o
f t
he
ra
ck
e
ar
s
5.
2"
(1
32
m
m
)
3U
Ov
er
al
l D
ep
th
16
.6
7"
(4
23
m
m
)
CH 1
GAIN/dB CH 2 CH 1 CH 2
ON
OFF
POWER
GAIN/dB
PROFESSIONAL POWER AMPLIFIER FULL SYMMETRY DUAL DIFFERENTIAL HIGH CURRENT DESIGN
 The M•2600 uses a unique T-Design constant gradi-
ent cooling tunnel that draws air in through the front
of the amplifier and forces it through the amplifier’s
sides. The T-Tunnel design provides a shorter, more
direct path for cool air. This allows for reduced heat
build up and cooler transistor operation.
 The amplifier has a subwoofer mode that allows
you to turn on the built-in subwoofer crossover. When
activated, the signals appearing at the left and right
inputs are summed, directed to a low-pass filter, and
routed to both output stages. A switch selects the cut-
off frequency of the filter at 60Hz, 90Hz, or 120Hz.
