MACKIE M2600 - Manual (Page 2)

High-Current Power Amplifier
M•2600
AMPLIFIER
M•2600
oF 6 PAGES
2
O F 6 P A G E S
High-Current Power Amplifier
M•2600
oF 6 PAGES
3
O F 6 P A G E S
High-Current Power Amplifier
M•2600
oF 6 PAGES
4
O F 6 P A G E S
M•2600 Specifications
Maximum Power mid-band at 1% THD:
500 watts per channel into 8 ohms
850 watts per channel into 4 ohms
1300 watts per channel into 2 ohms
1700 watts into 8 ohms bridged mono
2600 watts into 4 ohms bridged mono
Continuous Sine Wave Average Output Power, both
channels driven (20Hz - 20kHz):
425 watts per channel into 8 ohms <0.025% THD
700 watts per channel into 4 ohms <0.050% THD
1000 watts per channel into 2 ohms <0.1% THD
Bridged mono operation (20Hz - 20kHz):
1400 watts per channel into 8 ohms: <0.05% THD
2000 watts per channel into 4 ohms <0.1% THD
Power Bandwidth:
20Hz to 70kHz (+0, –3dB) @ 700 Watts into 4 ohms
Frequency Response:
20Hz to 40kHz (+0, –1dB)
10Hz to 70kHz (+0, –3dB)
Distortion:
THD, SMPTE IMD, TIM
<0.025%@8Ω
<0.050%@4Ω
<0.150%@2Ω
Signal to Noise Ratio
>107dB relative to rated power into 4 ohms
Channel Separation:
>80dB@1kHz
Damping Factor:
>350 from 0 to 400Hz
Input Impedance:
24kΩ balanced bridging
Input Sensitivity:
1.23 volts (+4 dBu) for rated power into 4 ohms
Gain:
32.7 dB (voltage gain of 43)
Maximum Input Level:
9.75 volts (+22 dBu)
Rise Time:
<5
µs
Slew Rate:
Voltage Slew Rate
>60V/µs
Current Slew Rate >30A/µs at 2Ω
CMRR:
>40 dB, 20Hz to 20kHz
Transient Recovery:
<1µs for 20dB overdrive at 1kHz
High-Frequency Overload and Latching:
No latch up to any frequency or level
Variable Low-Cut Filter:
10Hz (Off) to 170Hz, 2nd Order Bessel
Internal Crossover:
Switched 60Hz/90Hz/120Hz, 4th Order Linkwitz-Riley
Amplifier input is low-pass filtered when switched to sub-
woofer mode
Low-pass and high-pass outputs switchable to thru output
jacks
Limiter Section:
Complementary Positive and Negative Peak Detecting
Indicators:
6 meter LEDs per channel
SIG (Signal Present), –20, –9, –6, –3, OL (Overload)
CH1 & 2
PROTECT LEDs
SHORT LEDs
TEMP STATUS
COLD/HOT LEDs
Power Consumption:
1650 watts (18.2A) with musical program fully loaded
(2Ω per side, or 4Ω bridged)
AC Line Power:
US
120 VAC, 60Hz
Europe 240 VAC, 50/60Hz
Japan 100 VAC, 50/60Hz
Korea 220 VAC, 60Hz
AC Drop-out Voltage:
At approximately 63% of rated line voltage
Physical:
Height:
5.20" (132mm)
Width: 19.00" (483 mm)
Depth: 15.65" (398 mm)
Overall Depth: 16.67" (423 mm)
Weight: 55 lbs (25 kg)
