ENGLISH
Explanation of general view
1
Set plate
2
Battery cartridge
3 Charging light
4 Tank holder installing portion
5 Tank
6 Screw (A)
7 Screw (B)
8 Tank holder
9 Diamond wheel
0
Bolt
q
Flange
w
Blade stopper pin
e Tighten
r Loosen
t Hex wrench
y Depth guide
u Bolt (A)
i Bevel scale plate
o Bolt (B)
p Blade case
a Base
s For straight cuts
d
For 45° bevel cuts
f Lock-off lever
g Switch trigger
h Cap
SPECIFICATIONS
Model 4190D 4190DB
Wheel diameter ............................................................................ 80 mm 80 mm
Cutting depth
90° ............................................................................................. 0 – 18 mm 0 –18 mm
45° ............................................................................................. 0 – 16 mm 0 – 16 mm
No load speed (min -1 ) .................................................................. 1,000 1,000
Overall length ............................................................................... 313 mm 313 mm
Net weight .................................................................................... 1.9 kg 1.9 kg
Rated voltage ............................................................................... D.C. 9.6 V D.C. 9.6 V
• Due to our continuing program of research and
development, the specifications herein are subject
to change without notice.
• Note: Specifications may differ from country to
country.
Safety hints
For your own safety, please refer to the enclosed
safety instructions.
IMPORTANT SAFETY INSTRUCTIONS
FOR CHARGER & BATTERY
CARTRIDGE
1. SAVE THESE INSTRUCTIONS — This manual
contains important safety and operating
instructions for battery charger.
2. Before using battery charger, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
3. CAUTION — To reduce risk of injury, charge
only MAKITA type rechargeable batteries.
Other types of batteries may burst causing
personal injury and damage.
4. Do not expose charger to rain or snow.
5. Use of an attachment not recommended or
sold by the battery charger manufacturer may
result in a risk of fire, electric shock, or injury
to persons.
6. To reduce risk of damage to electric plug and
cord, pull by plug rather than cord when dis-
connecting charger.
7. Make sure cord is located so that it will not be
stepped on, tripped over, or otherwise sub-
jected to damage or stress.
8. Do not operate charger with damaged cord or
plug — replace them immediately.
9. Do not operate charger if it has received a
sharp blow, been dropped, or otherwise dam-
aged in any way; take it to a qualified service-
man.
10. Do not disassemble charger or battery car-
tridge; take it to a qualified serviceman when
service or repair is required. Incorrect reas-
sembly may result in a risk of electric shock or
fire.
11. To reduce risk of electric shock, unplug
charger from outlet before attempting any
maintenance or cleaning. Turning off controls
will not reduce this risk.
ADDITIONAL SAFETY RULES FOR
CHARGER & BATTERY CARTRIDGE
1. Do not charge battery cartridge when tempera-
ture is BELOW 10°C (50°F) or ABOVE 40°C
(104°F).
2. Do not attempt to use a step-up transformer,
an engine generator or DC power receptacle.
3. Do not allow anything to cover or clog the
charger vents.
4. Always cover the battery terminals with the
battery cover when the battery cartridge is not
used.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water or
rain.
A battery short can cause a large current flow,
overheating, possible burns and even a break-
down.
4
