Maxtor’s DiamondMax
Plus 45 series delivers
outstanding performance
including:

• 15.4 GB of data storage

per platter

• Fast data transfer rates

(up to 100 MB/sec)

• 7200 RPM spin speed

• < 8.7 ms average seek

• 2 MB cache buffer

• 3-year warranty

E R F O R M A N C E

P E C I F I C A T I O N S

Seek Times (typical)

Track to Track

1 ms

Average

< 8.7 ms

Full Stroke

< 20 ms

Average Latency

4.17 ms

Rotation Speed (± 0.1%)

7200 RPM

Controller Overhead

< 0.3 ms

Start Time (0 - drive ready)

8.5 sec typical

ATA

R A N S F E R

AT E S

To/From Interface

up to 100 MB/sec

To/From Media

up to 49.5 MB/sec

R I V E

O N F I G U R A T I O N

Integrated Controller

Ultra ATA/100

Buffer Size

2 MB

Buffer Type

SDRAM

Data Zones per Surface

Bytes per Sector/Block

512

E L I A B I L I T Y

P E C I F I C A T I O N S

Start/Stop Cycles

50,000 (minimum)

Component Design Life

5 years (minimum)

Data Errors (non-recoverable)

< 10 per 10E15 bits read

Annual Return Rate (ARR)

< 1%

O W E R

E Q U I R E M E N T S

(

T Y P I C A L

)

O D E

1 2 V ± 1 0 %

5 V ± 5 %

O W E R

Spin-up (peak)

2500 mA

620 mA

Seek

800 mA

510 mA

12.9 W

Read/Write

525 mA

515 mA

9.0 W

Idle

350 mA

490 mA

6.6 W

Standby

30 mA

270 mA

1.75 W

N V I R O N M E N T A L

I M I T S

C O U S T I C S

Idle mode

3.3 bel (average sound power)

E M P E R AT U R E

Operating

5° C to 55° C

Non-operating, Storage

-40° C to 71° C

E L AT I V E

U M I D I T Y

(

N O N

C O N D E N S I N G

)

Operating, Non-operating, Storage

5% to 95%

Maximum Wet Bulb, Operating

30° C

I B R AT I O N

Operating, random, no errors

10 to 45 Hz at 0.004 G2/Hz
48 to 62 Hz at 0.008 G2/Hz

65 to 300 Hz at 0.004 G2/Hz

301 to 500 Hz at 0.0006 G2/Hz

Non-operating, random 10 to 2,000 Hz at 2.15 Grms, no damage
Operating, swept sine (1 octave per minute)
10 to 300 Hz

1.0 G peak amplitude

H O C K

Operating Mechanical Shock

30 Gs, 2 ms, no errors

Non-operating Mechanical Shock

300 Gs, 2 ms, no damage

H Y S I C A L

I M E N S I O N S

(

M A X I M U M

)

Height

1.02 in

2.61 cm

Length

5.78 in

14.70 cm

Width

4.02 in

10.21 cm

Weight

1.30 lbs

0.59 kg

All Maxtor products are backed by the

No Quibble Service

policy, the benchmark

for service and support in the industry.

No Quibble includes:

• Advance replacement in 2 business days

• MaxFax

24-hour automated technical support

• Maxtor’s commitment to total customer satisfaction

• Phone technicians available Monday– Friday

For more information or to talk to a customer support representative, call: (U.S. and Canada)
800-2MAXTOR. Available 5

.– 5

. (PT) Mon – Fri; (Europe) +353 1 204 1111. Available

9:30

.– 6

. (CET) Mon –Thurs and 9:30

.– 5

. (CET) Fri; (Asia/Pacific) 800-481-6788.

Available 8

.– 5:30

. (GMT+8) Mon – Fri; or visit our home page on the Internet at

http://www.maxtor.com.

Specifications subject to change without notice. Maxtor defines 1 megabyte as 10

or 1 million bytes and 1 gigabyte as

or 1 billion bytes.

Acoustics measured at sea level.

Without non-recoverable errors. Adaptive ATA Control

, DualWave

MaxSafe

, Silent Store

and ShockBlock

are trademarks of Maxtor. DiamondMax

, Maxtor

, MaxFax

and No Quibble

Service

9/00 Stock #DMP45/4827 Rev. B

Best Hard Drive

DiamondMax 60 (60 GB)

PC World, June 2000

Kick Ass Product

DiamondMax Plus 40 (40 GB)

Maximum PC, April 2000

Best Buy

DiamondMax Plus 40 (40 GB)

Computer Shopper, April 2000

Win100 Award 2000

DiamondMax Plus 40 (40 GB)

Winmag.com, June 2000

MODEL

54610H6

53073H4

52049H3

51536H2

CAPACITY

46103 MB

30735 MB

20491 MB

15367 MB

HEADS

PLATTERS
