Makita 6932 - Manual (Page 2)

2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
GENERAL SAFETY RULES
USA003-2
(FOR ALL BATTERY OPERATED TOOLS)
WARNING:
Read and understand all instructions. Failure to follow all
instructions listed below, may result in electric shock, fire and/or
serious personal injury.
Model 6932FD
Capacities
Machine screw 4 mm - 8 mm (5/32” - 5/16”)
Standard bolt 5 mm - 14 mm (3/16” - 9/16”)
High tensile bolt 5 mm - 10 mm (3/16” - 3/8”)
No load speed (RPM) 0 - 2,400/min.
Impacts per minute 0 - 3,200
Overall length 165 mm (6 - 1/2”)
Net weight 1.7 kg (3.7 lbs)
Battery Charger DC1414
Input A. C. only 50 Hz - 60 Hz
Output D. C. 7.2 V - 14 V
Battery Cartridge 1420 1422 1434 1435
Voltage 14.4 V
Charging time 30 min. 45 min. 60 min. 70 min.
