- 11 -
Size 43cm/17" (41cm/16" Viewable Image Size)
Mask type Aperture grille
Gun In-line
Deflection angle 90 °
CRT Phosphors Red, Green, Blue EBU (medium short persistence)
Aperture grille pitch 0.25mm
Face Plate Anti-glare, Anti-reflection and Anti-static film
Focusing method Dynamic Beam Forming (DBF)
Video 0.7V analog RGB
Sync Separate H, V sync., or Composite sync
Input Connectors DB9-15P
Input Impedance 75
Ω (video), 2.2kΩ(sync.)
SCANNING Horizontal 31 - 70kHz
FREQUENCY Vertical 55 - 120Hz
RESOLUTION (HxV) 1280 dots x 1024 lines Non-Interlaced maximum addressable resolution format at 75Hz
WARM-UP TIME 30 minutes to reach optimum performance level
BRIGHTNESS 100cd/m 2 , standard full white video signal at 9300K (+ 8MPCD)
Horizontal 3.6
µsec (typ.)
Vertical 530
µsec (typ.)
DISPLAY SIZE 310mm x 232mm(typ.) ratio 4:3
COLOUR 5000K~9300K
AC100-240V ±10% 50/60Hz 73W (typ.)
OPERATING Temperature 10 - 35
°C
ENVIRONMENT Humidity 30 - 80%RH (without condensation)
DIMENSIONS (W)15.9inch x (H)16.5inch x (D)16.5inch / (W) 403mm x (H) 420mm x (D) 420mm
WEIGHT Approx. 16.4kg / 36.2lbs.
TILT/SWIVEL Tilt Angle -5 ° - +10°
BASE Swivel Angle
±90°
Safety UL1950 (UL), CSA C22.2 No.950 (C-UL)
EN60950 (TÜV-GS)
EMC FCC Class-B, DOC Class-B
EN55022 Class-B, AS/NZS 3548 Class-B
EN50082-1, EN61000-3-2, EN61000-3-3, EN55024
REGULATIONS X-Ray DHHS, HWC, Röv vom 8.1, 1987
Other CE-Marking, MPR-II/TCO'91
ISO9241-3, ISO9241-7, ISO9241-8 (TÜV-GS)
TCO '99
International E NERGY S TAR Program
6 6
SPECIFICATIONS
INPUT SIGNAL
SIGNAL INTERFACE
BLANKING TIME
POWER SOURCE
This monitor is registered / certified with Model No. N0701. *
< =
< =
