9 Replacement Parts List
Note: Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
CF-W4HWEZZBM
REF.NO. and AREA
PART NO.
DESCRIPTION
Q'TY
Main Block Unit
CN12
K1FB315BA003
VGA CONNECTOR
1
CN13
K1NA09E00076
CONNECTOR
1
CN14
K1NA68E00096
CONNECTOR
1
CN601
K1KA10B00233
CONNECTOR
1
CN902
K1FB104B0055
USB CONNECTOR
1
CN903
K1FB104B0055
USB CONNECTOR
1
JK1
K2HC103B0205
HEADPHONE JACK
1
JK2
K2HC103B0205
MICROPHONE JACK
1
SW5
K0ZZ00000617
SLIDE SW
1
SW6
ESD165225
POWER SW
1
SW7
K0D112B00071
W-LAN SW
1
SW951
K0D113B00081
SLIDE SW
1
E1
CR-2032/K5A
COIN BATTERY
1
E2
DFJK12U112BB
PAD FFC
1
E3
DFJK20T108BB
SW PCB FFC
1
E4
DFJK9000ZA
DRIVE FFC
1
E5
DFJS957ZA
LCD CABLE
1
E6
DFJS979ZA
LAN CABLE
1
E7
DFJS959ZB
MODEM CABLE
1
E8
DFJS960ZA
MAIN SUB CABLE
1
E9
DFJS961ZB
DC-IN CABLE
1
E10
DFJS962ZA
SP CABLE
1
E11
DL3U11436VBB
PCB, MAIN
RTL
1
E12
DL3U21436VBB
PCB, USB
RTL
1
E13
DL3UP1492KAA
PCB, SW
RTL
1
E14
N1ZYYY000002
ANTENNA PCB-L ASSY
1
E16
N1ZYYY000001
ANTENNA PCB-R ASSY
1
E18
N5HZC0000014
WIRELESS LAN MODULE
1
E19
UJDA769PD1-A
CD-R/RW, DVD-ROM DRIVE
1
E20
DL3UP1443AAA
FPC, HDD
1
E21
N3CAYYY00006
HDD
1
E22
K1YYZZ000060
CONNECTOR
1
E23
L0AA01A00018
SPEAKER
1
E24
L5EDD3Q00023
LCD
1
E25
L9AAA5DB0010
SOLENOID
1
E26
N0GB1J000012
INVERTER
1
E27
N2AZZJ000038
KEY BOARD US
1
E28
N2EAYYY00006
TOUCH PAD
1
E29
N5HAZ0000012
MODEM
1
Accessories
A1
CF-AA1623AM6
AC ADAPTOR
1
A2
K2CG3DR00003
AC CABLE
1
A3
N4HULTA00009
LITHIUM ION BATTERY PACK
1
A4
DFQX5574ZA
MANUAL
1
A500
DFJS954ZA
MODEM CABLE
1
Packing Material
P1
DFPE0806ZB
HOLDER
1
P2
DFPE0812ZB
PAD W
1
P3
DFPE0819ZA
BATTERY SPACER
1
P5
DFPK1037YA
ACCESSORIES BOX
1
P6
DFPK1194YA
PACKING CASE (EXPORT)
1
