Controlling the Monitor with a PC (RS-232C)

PIP/PbyP menu

Function

Command

Direction

Parameter

Reply

Control/Response contents

*

PIP MODES

MWIN

WR

0-3

0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2

B

PIP SIZE

MPSZ

WR

1-12

1-12

B

PIP POS

THE LONGEST
DIRECTION

MHPS

W

0-100

B

R

0-100

B

THE SHORTEST
DIRECTION

MVPS

W

0-100

B

R

0-100

B

PIP POS LD+SD BATCH

MPOS

W

0-100,0-100

Specify the position in MPOSxxxyyy format.
(xxx: Longer side, yyy: Shorter side position)

B

R

0-100,0-100 Returns a response in (xxx,yyy) format.

(xxx: Longer side, yyy: Shorter side position)

B

PIP BLEND

MWBL

WR

0-15

0-15

B

PIP SOURCE

MWIP

WR

1

1 PC1 DVI-D

B

2

2 PC3 D-SUB

3

3 AV3 COMPONENT

4

4 AV5 VIDEO

6

6 PC4 RGB

7

7 AV1 DVI-D

8

8 AV4 S-VIDEO

9

9 AV2 HDMI

10

10 PC2 HDMI

SOUND CHANGE

MWAD

WR

1-2

1-2 1: MAIN, 2: SUB

B

MAIN POS (Main screen)

MWPP

WR

0-1

0-1 0: POS1, 1: POS2

B

PbyP2 POS (Sub screen)

MW2P

WR

0-2

0-2 0: POS1, 1: POS2, 2: POS3

B

AUTO OFF

MOFF

WR

0-1

0-1 0: MANUAL, 1: AUTO

B

Initialization/Functional Restriction Setting (FUNCTION) menu

Function

Command

Direction

Parameter

Reply

Control/Response contents

*

ALL RESET

RSET

W

0-1

0: ALL RESET 1, 1: ALL RESET 2

-

ADJUSTMENT LOCK

ALCK

WR

0-2

0-2 0: OFF

B

OSD DISPLAY

LOSD

WR

0-1

0-1 0: ON, 1: OFF

B

LED

OFLD

WR

0-1

0-1 0: ON, 1: OFF

B

TEMPERATURE ALERT

TALT

WR

0-2

0-2 0: OFF, 1: OSD & LED, 2: LED

B

STATUS ALERT

SALT

WR

0-2

0-2 0: OFF, 1: OSD & LED, 2: LED

B

Others

Function

Command

Direction

Parameter

Reply

Control/Response contents

*

SCREEN SIZE (PC)

WIDE

WR

1-5

1-5 1: WIDE, 2: NORMAL, 3: Dot by Dot, 4: ZOOM1, 5: ZOOM2

B

SCREEN SIZE (AV)

WIDE

WR

1-5

1-5 1: WIDE, 2: ZOOM1, 3: ZOOM2, 4: NORMAL, 5: Dot by Dot

B

VOLUME

VOLM

WR

0-31

0-31

B

MUTE

MUTE

WR

0-1

0-1 0: OFF, 1: ON

-

INFORMATION

MODEL

INF1

R

Value

A

SERIAL NO

SRNO

R

Value

BRIGHT

VLMP

WR

0-31

0-31 Brightness

B

TEMPERATURE SENSOR

DSTA

R

0 Internal temperature normal

A

1 Internal temperature abnormal (Standby mode)
2 Internal temperature abnormal (Temperature is normal now, but it was

abnormal during operation.)

3 Internal temperature abnormal (Brightness of the backlight decreases.)
4 Temperature sensor abnormal

TEMPERATURE ACQUISITION

ERRT

R

Value Temperature at temperature sensors 1 through 3 are returned in the

following forms:
[Sensor 1], [Sensor 2], [Sensor 3]
Indicates a temperature sensor abnormality when “126” is returned.

A

CAUSE OF LAST STANDBY MODE

STCA

W

0

Initialization

A

R

0 No detectable error has occurred
1 Standby mode by POWER button
2 Main power “OFF” by the main power switch
3 Standby mode by RS-232C or LAN
4 Waiting mode by No Signal (Incl: VESA DPMS/DMPM)
6 Standby mode by abnormal temperature
8 Standby mode by SCHEDULE setting
