95-7868B DASH DISASSEMBLY
2
Remove (3) Phillips screws and (1)
push pin per side of radio to remove
radio. (Figure G) 8
Remove (2) Phillips screws from
storage pocket assembly above radio
to separate. (The storage pocket
assembly will have to be attached to
the radio housing in the kit assembly
next) 9
Continue to kit assembly.
E
F
G
ACURA CL 2001-2003 / TL 1999-2003
Unclip and remove seat heater switch
trim panel to access (2) Phillips
screws and remove screws. (Figure E) 6
Unclip bottom of A/C control trim
panel and pull away (no need to
completely remove). (Figure F) 7
