95-7868B DASH DISASSEMBLY
ACURA CL 2001-2003 / TL 1999-2003
1
1
Open armrest and remove (2) Phillips
screws inside and (2) Phillips at front
edge of rear of console and pull
rearward. (Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unclip and remove wood trim from
both sides of center console.
(Figure A) 2
Open fuse access and remove (1)
Phillips screw then unclip and remove
panel below steering column.
(Figure C) 4
Remove (3) Phillips screws per center
console side panel and unclip and
remove panels (driver’s side and
passenger side). (Figure D) 5
Continued on page 2.
A
B
C D
