OM-316 Page 12
4-3. Volt-Ampere Curves
A. For AC/DC Models
193 509 / 193 510 / 193 511 / 193 512
The volt-ampere curves show the
minimum and maximum voltage
and amperage output capabilities.
Curves of other settings fall be-
tween the curves shown.
A. For 115/230, 230 And 460 Volt Models
(225/150 Amperes)
B. For 220, 230/400, And 460 Volt Models
(300/200 Amperes)
0
10
20
30
40
50
60
70
80
90
100
0 100 200 300 400
DC Amperes
DC V
olts
MIN MAX
0
10
20
30
40
50
60
70
80
90
100
0 50 100 150 200 250 300 350 400 450
AC Amperes
A=LOW RANGE
B=HIGH RANGE
A A B B
0
10
20
30
40
50
60
70
80
0 50 100 150 200 250
DC Amperes
DC V
olts
0
10
20
30
40
50
60
70
80
90
0 50 100 150 200 250 300 350
AC Amperes
AC V
olts
AC V
olts
