SECTION 9 − PARTS LIST
9-1. Drive Roll And Wire Guide Kits
.
Base selection of drive rolls upon the following recommended usages:
1 V-Grooved rolls for hard wire.
2 U-Grooved rolls for soft and soft shelled cored wires.
3 U-Cogged rolls for extremely soft shelled wires (usually hard surfacing types).
4 V-Knurled rolls for hard shelled cored wires.
5 Drive roll types may be mixed to suit particular requirements (example: V-Knurled roll in combination
with U-Grooved).
Ref. S-0026-B/7-91
Wire Diameter
Fraction Decimal Metric
.023/.025 in.
.030 in.
.035 in.
.045 in.
.023/.025 in.
.030 in.
.035 in.
.045 in.
0.6 mm
0.8 mm
0.9 mm
1.2 mm
Kit No.
087 131
079 594
079 595
079 596
Drive Roll
Part No. Type
087 130
053 695
053 700
053 697
V-Grooved
V-Grooved
V-Grooved
V-Grooved
Inlet
056 192
056 192
056 192
056 193
Wire Guide
.030/.035 in. .030/.035 in. 0.8/0.9 mm 204 579 203 526 V-Grooved 056 192
