SWA2801z SPECIFICATIONS
Dimensions
39.19 in/
995.3 mm
34.00 in/
863.6 mm
37.00 in/
939.8 mm
24.62 in/
625.3 mm
FIXED
SWIVEL
System Specifications
Freq range (– dB) Hz – 10 Hz
Freq range (–10 dB) Hz – 00 Hz
Maximum SPL @ 1m 10 dB
Peak Output SPL @ 1m 16 dB
Crossover frequency
10 Hz
Input type Balanced differential
Input protection Level protected
Thermal protection Input stage muting,
auto-reset
Input/Output
Input: Stereo bal/unbal.
female XLR
Input Impedance: 50 kΩ
Loop Through: Stereo bal/unbal.
male XLR
High-Pass Output: Stereo bal/unbal.
male XLR
Level Control: Rotating knob, center
detent, off to +15 dB)
Phase Control: (0– 180 degrees)
Recessed Sliding Switch
Transducer Specifications
Diameter 18” (57 mm)
Voice coil diameter ” (10 mm)
Power Amplifier
Rated Power 800 watts continuous
1000 watts peak
Rated THD < 0.0%
Cooling Passive
Line Input Power
US Model 10 VAC, 60 Hz
Recommended Amperage Service: 15A
European Model
0 VAC, 50 Hz
Recommended Amperage Service: 8A
Physical Properties
Height 7.00 in/99.8 mm
Width .6 in/65. mm
Depth .00 in/86.8 mm
Weight 15 lb/70 kg
Enclosure 15 mm thick multi-
layer Baltic birch wood
Mounting Methods Floor mount only
WARNING: The cabinet has no rigging points
and is not suitable for rigging. NEVER attempt
to suspend the SWA801z by its handles.
Disclaimer
Since we are always striving to make our
products better by incorporating new and
improved materials, components, and manufac-
turing methods, we reserve the right to change
these specifications at any time without notice.
