Marantz MAR770 - Manual (Page 44)

48
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PP16-REAR PANEL
CIRCUIT BOARD
PP16-CAPACITORS
C301 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C311 5322 122 32265 CER. 100pF J CH 50V BLK DD15101300
C312 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C313 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C314 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C651 5322 122 32265 CER. 100pF J SL 50V GRN DD15101300
C652 5322 122 32265 CER. 100pF J CH 50V BLK DD15101300
C653 4822 124 12404 ELECT. 220µF 16V RA-2 OA22701620
C655 4822 124 80119 ELECT. 1000µF 25V ARS OA10702540
C656 4822 124 80119 ELECT. 100µF 25V ARS OA10702540
C681 5322 122 32265 CER. 100pF J CH 50V BLK DD15101300
C682 5322 122 32265 CER. 100pF J CH 50V BLK DD15101300
C683 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C701 5322 122 32265 CER. 100pF J CH 50V BLK DD15101300
C702 5322 122 32265 CER. 100pF J SL 50V GRN DD15101300
CF51 CER. 470pF ±10% DK16471300
CF52 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CN51 4822 122 40617 CER. 50V DC 0.1µF +80-20% DD38104010
CT01 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT02 4822 126 10513 CER. 47pF DA15470110
CT03 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CT04 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT05 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CT51 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT52 482212610513 CER. 47pF DA15470110
CT53 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CT54 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT55 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CY11 9965 000 00368 CER. 0.047µF Z 50V DA17473110
PP16-RESISTOR
R311 4822 111 41355 RES. 75
Ω
±5% 1/6W GD05750160
PP16-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R312-R314
R651-R656 R683-R686
RF51-RF57 RN51-RN58 RT01
RT02 RT51 RT52
PP16-SEMICONDUCTORS
DF51 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
Q311 4822 209 63182 IC LC74HCU04 HC700400U0
Q681 4822 209 63182 IC LC74HCU04 HC700400U0
QF51 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QF52 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QN51
4822 130 43818 TRS. 2SC2878 A HT328781A0
QN58
PP16-MISCELLANEOUS
J301 4822 218 11487 OPT. CONNECTOR
GP1F32R OPTICAL RECIVER
YJ15000150
J311 4822 290 81638 TERMINAL 14X14 RCA 1L1P YT02010790
J651 4822 265 31045 TERMINAL YKC21-3337 RCA YT02021080
J681 4822 265 31045 TERMINAL YKC21-3337 RCA YT02021080
J682 JACK FFC CONNECTOR
07P 9604S-07C YJ07011370
J701 4822 265 31045 TERMINAL YKC21-3337 RCA YT02021080
JF51 4822 267 41009 TERMINAL 2P RCA RC-5 YT02020890
JJ01 JACK 14FMN-BTRK YJ07019380
JT01 4822 290 81638 TERMINAL 14X14 RA 1L1P BLK YT02010790
JT02 4822 267 31369 OPT. CONNECTOR
GP1F32T OPTICAL OUTPUT
YJ15000090
JT51 4822 290 81638 TERMINAL 14X14 RA 1L1P BLK YT02010790
JT52 4822 267 31369 OPT. CONNECTOR
GP1F32T OPTICAL OUTPUT
YJ15000090
L311 FERRITE BEAD
BL02RN2-R62T2 FC90050130
L651 FERRITE BEAD
BL02RN2-R62T2 FC90050130
L652 FERRITE BEAD
BL02RN2-R62T2 FC90050130
L681 FERRITE BEAD
BL02RN2-R62T2 FC90050130
L682 FERRITE BEAD
BL02RN2-R62T2 FC90050130
L701 FERRITE BEAD
BL02RN2-R62T2 FC90050130
L702 FERRITE BEAD
BL02RN2-R62T2 FC90050130
LF51 FERRITE BEAD
BL02RN2-R62T2 FC90050130
LT01 FERRITE BEAD
BL02RN2-R62T2 FC90050130
LT02 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LT03 FERRITE BEAD
BL02RN2-R62T2 FC90050130
LT51 FERRITE BEAD
BL02RN2-R62T2 FC90050130
LT52 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LT53 FERRITE BEAD
BL02RN2-R62T2 FC90050130
SF51 4822 277 21559 SLIDE SWITCH INT/EXT SS02021150
PY16-FRONT CIRCUIT BOARD
PY16-CAPACITORS
CY03 4822 1224 0588 CER. 0.022µF TP050F223Z DA17223110
CY04 4822 1261 0362 CER. 22pF DA15220110
CY05 48221 261 0362 CER. 22pF DA15220110
CY06 9965 00000368 CER. 0.047µF Z 50V DA17473110
CY07 4822 124 21901 ELECT. 47µF 6.3V EJ47600610
CY08 9965 000 00368 CER. 0.047µF Z 50V DA17473110
CY09 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CY10 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CY12 4822 124 21901 ELECT. 47µF 6.3V EJ47600610
PY16-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
RY01-RY15 RY21-RY28
PY16-SEMICONDUCTORS
DY02 4822 130 11569 L.E.D. HLMF-K200 #2UL RED HI10005340
DY03 4822 130 11569 L.E.D. HLMF-K200 #2UL RED HI10005340
DY04 5322 130 31504 ZENER DIODE MTZ J 3.3A HD30331000
PY16-MISCELLANEOUS
QY01 9965 000 06374 MICROPROCESSOR
TMP87CH74F
HU385KT000
QY02
4822 130 41947 TRS. 2SC2458 2SC1740S HT30001000
QY04 2SC3199 ETC.
LY01 4822 157 62919 CHOKE COIL 100µH J% LC11043800
SY01
4822 276 13732 PUSH SWITCH SKQNAE SP01013310
SY09 H/5MM 160GF
