9. WIRING DIAGRAM
De-soldering and remove cables
W651
from the loader
PCB.
REMARK
When replace the CDR module MAR775 to
the new one.
It is necessary to add removed cables at
same positions as follows;
WHITE
+ side lead of capacitor 2424
PINK
+ side lead of capacitor 2430
W651
+ side 2430
+ side 2424
DISMOUNTING ADDITIONAL CABLES
....
.....
