Hardware Software Interface (HSI) Spec. Page: 13 / 19
SR7300/SR7300OSE Document Version [2.01]
3-5. Status request and Status answer list
3-5-1. Normal Status request and Status answer list
(Samples indicated the ID set to as ‘1’.)
Request Status Char. & Sample Status answer Char. & Sample
POWER ON A0 (“@1A0”,0x0D)
POWER Status ‘A’ (“@1?A”,0x0D)
POWER OFF A1
DSS B0
TV B1
LD B2
DVD B3
VCR-1 B4
VCR-2 B5
AUX1 B6
AUX2 B7
VIDEO INPUT ‘B’ (“@1?B”,0x0D)
DVD-R B8
DSS C0
TV C1
LD C2
DVD C3
VCR-1 C4
VCR-2／DVD-R C5
AUX1 C6
AUX2 C7
DVD-R C8
CD C9
TAPE CA
CD-R CB
FM (/TUNER)
CC
AM CD
MW
CE
LW CF
MULTI-CHANNEL INPUT
CG
AUDIO INPUT ‘C’ (“@1?C”,0x0D)
TUNER CH
DIGIAL D0
INPUT MODE ‘D’ (“@1?D”,0x0D)
ANALOGUE D1
TUNER FREQUENCY
E0xxxx:(Not tuned+Freq.)
E1xxxx:(Tuned+Freq.)
(FM: 87.55 = “8755”)
(FM:108.00 = “0800”)
(MW: 520=”0520”)
(LW:282=”0282”)
Frequency Scaning E2 (“@1E2”!,0x0D)
TUNER FFREQUENCY
‘E’ (“@1?E”,0x0D)
FM:076.0-108.0
AM,MW:520-1710
LW:152-282
Not available E- (“@1E-“,0x0D)
Preset No (XX=01～50)
Not Preset mode (XX=00)
F0XX
TUNER PRESET ‘F’ (“@1?F”,0x0D)
Not available F- (“@1F-“,0x0D)
AUTO STEREO G1
MONO G0 TUNER MODE ‘G’ (“@1?G”,0x0D)
Not available G-
VOL.= XXXdB
(XXX = -90～+99) H0XXX
(“@1H0-15”,0x0D)
max H1
VOLUME Status ‘H’ (“@1?H”,0x0D)
min （-∞） H2
BASS Status ‘I’ (“@1?I”,0x0D) BASS:xxdB(xx=-9～+9) I0xx
TREBLE Status ‘J’ (“@1?J”,0x0D) TREBLE:xxdB(xx=-9～+9) J0xx
ATT ON
K1
ATT Status ‘K’ (“@1?K”,0x0D)
ATT OFF K0
