Specifications – Mark Levinson Reference Preamplifier N32 User Manual

Page 32

Specifications

The correlation between published specifications and sonic quality is unreliable. A list
of numbers reveals virtually nothing. All technical measurements must be subject to
qualitative as well as quantitative interpretation.

Measurements of the Nº32 yield excellent results by any standards. However, only
those specifications that apply to its actual operation are included here.

■

Frequency response:

RIAA response

0.1 dB

RIAA/IEC response

+0.1, -0.3 dB

■

Gain:

either 40 or 60 dB

■

THD + N:

2V out, 1 kHz test signal, 80 kHz measurement bandwidth

less than 0.008%

■

Residual noise
ref to output w/500

V, 1 kHz at input, unweighted:

-69 dB

■

Input connectors:

2x Madrigal RCA per channel,

or 2x Neutrik XLR per channel

■

Input impedance:

(user selectable)

Resistive:

3.3

Ω

, 5

Ω

, 7.7

Ω

, 10

Ω

, 33

Ω

, 50

Ω

, 77

Ω

, 100

Ω

, 330

Ω

, 47k

Ω

Capacitive:

0pF, 50pF, 100pF, 150pF, 200pF, 250pF, 300pF, 350pF, 0.01

Gold-plated, solderless terminals are available for user-installed load value,
inside phono module.

■

Input overload:

1kHz, 60 dB gain:

16mV on XLR, 8mV on RCA

1kHz, 40 dB gain:

160mV on XLR, 80mV on RCA
