Model 5001z Owner’s Manual
Page 5 www.midlandradio.com
Installation Continued... Installation Continued...
Power Wiring (negative ground only)
Step 1: If you have not determined whether your vehicle has a negative or positive
ground, do so now. Then disconnect the negative lead from the battery to prevent short
circuits that can occur during wiring. Do not connect this transceiver to positive ground
electrical systems.
Step 2: With negative ground:
A. Connect the positive (RED WIRE) the one with in-line fuse holder to either the
( a ) fuse block
( b ) cigarette lighter or
( c ) directly to the positive post on your battery.
Usually, the fuse block is the most convenient connecting point. It is also possible to
connect to the Accessory terminal on the fuse block or ignition switch, so that your CB
automatically goes off when the ignition goes off.
B. Then tightly connect the ground (BLACK WIRE) directly to the vehicle's metal frame. A
good direct metal-to-metal ground is essential for optimum performance.
Mounting the Main Unit
Step 1: Loosen the retaining knobs on each side of the mounting bracket to give enough
space for the unit to slide between the two bracket arms.
Step 2: Position the main unit between the bracket arms in line with the retaining knobs.
Set the height and angle for optimum operating comfort and accessibility.
Step 3: Tighten the retaining knobs.
Installation of Microphone Hanger
Mounting holes are provided on the microphone hanger bracket. The bracket can be
attached to the vehicle dash or other convenient location.
