95-7417
KIT ASSEMBLY
15
2
A
Attach the factory mounting brackets
and the 95-7417 DDIN trim
plate/bracket assembly to the
stacked ISO DIN head units with the
screws supplied with the units.
(Figure B)
Slide the appropriate bracket into
the trim plate aligning the holes in
the trim plate to the clips on the
bracket. (Figure A)
1
B
STACKED ISO DIN HEAD UNIT PROVISION
