14
95-7417 KIT ASSEMBLY
2
A
Attach the factory mounting brackets
and the 95-7417 DDIN trim
plate/bracket assembly to the DDIN
head unit with the screws supplied
with the unit. (Figure B)
Slide the appropriate bracket into
the trim plate aligning the holes in
the trim plate to the clips on the
bracket. (Figure A) 1
B
DOUBLE DIN HEAD UNIT PROVISION
