MGE UPS Systems POWER-SURE 700 User Manual
Page 37
Maintenance
3 —15
Installation and User Manual
Figure 3-10: Power-Sure™ 700 — 225-300kVA SCR Heatsink Assembly.
3.9
Field Adjustments of Circuit Cards
3.9.1
Power-Sure™ 700 Control Card #49120/407415
WARNING:
ALL SERVICE TO THIS PIECE OF EQUIPMENT MUST BY PERFORMED BY
QUALIFIED PERSONNEL.
GATE
LEADS
(TYPICAL)
FUSIBLE LINK
(CONTINUOUS
THROUGH EACH
POWER MODULE)
THERMAL
SENSOR
CABLE TO
TRANSFORMER
(TYPICAL)
POWER MODULE
HEATSINK
INPUT CABLE
DIODE
86-108814-00 B01
