This operator’s manual describes the McCulloch Zero
Turn Rider. The rider is fitted with a Briggs & Stratton
four-stroke overhead valve engine.
Control Locations
1 2 3 4
5 7 8 6
Transmission from the engine is made via belt-driven
hydraulic pumps. Using the left and right steering
controls, the flow is regulated and thereby the
direction and speed.
8077-004
Cutting height handle 1.
Park brake 2.
Throttle/Choke control 3.
Ignition switch 4.
Blade control lever 5.
Motion control levers 6.
Fuel tank cap 7.
Fuel shut off valve 8.
Bypass linkage 9.
9
