Makita HR2432 - Manual (Page 2)

Specifications Specifications
Capacities: Concrete 1"
Steel 1/2''
Wood 1-1/4"
No Load Speed 0 - 1,000 RPM
Blows per Minute 0 - 4,500
AMPS (120V) 6.7
Overall Length 16"
Net Weight 6.6 lbs.
Shipping Weight 16.5 lbs.
Master Carton Qty. 2
UPC Code 088381-06133-9
Accessories Accessories
■ Dust Bag Assembly (122708-7)
■ Side Handle (152521-9)
■
Bit Grease (181573-3)
■ Dust Cap (421727-3)
■ Tool Case (824729-2)
Standard Equipment Standard Equipment
Model HR2432
Features & Benefits Features & Benefits
■ Powerful 6.7 AMP motor and lightweight (6.6 lbs.); impact energy (1.6 ft.lbs.)
■ 3-mode operation; “rotation only,” “hammering with rotation” or “hammering only”
■ Large fan and dust bag for efficient dust collection
■ 0 - 1,000 RPM and 0 - 4,500 BPM (2.2 joules of impact energy) for demanding applications
■ One touch sliding chuck for easy bit changes; accepts SDS-Plus bits
■ Positive bit lock ensures that the bit is securely fastened
■ Durable hose is designed with elbow-shaped nozzle for longer life
■ Recessed lock-on button for continuous use
■ Large trigger switch and 360º swivel side handle for added comfort
■ Ergonomic well balanced design features a rubberized pistol grip for greater stability,
comfort and control with reduced operator fatigue
All specifications subject to change without prior notice. All models and accessories subject to stock on hand.
RHF-0605-7.5M MA-0353-05 For more information, call 1-800-4MAKITA
makitatools.com Makita U.S.A., 14930 Northam St., La Mirada, CA 90638
Makita offers a wide variety of accessories for 1'' Rotary Hammers. For a complete listing, please
refer to the Makita General Catalog, or visit our website at makitatools.com, or call 1-800-4MAKITA.
■ Thruster Style carbide tip penetrates
on contact and plows through rebar
■ Thruster Style reinforced ground flute
for efficient dust removal
■ Dynamic chisel shaped head keeps bit
in contact with the material at all times
■ Available individually, 5/pk and 25/pk
■ From 5/32" to 1" diameter
Thruster® Carbide-Tipped Bits Hammer Steel
■ Designed for long lasting performance
■ Strength and surface hardness maximize life
■ Available in Bull Point, Flat Chisel, Scaling
Chisel and Floor Scraper
Modular Thin Wall Core Bit System
■ For use in non-reinforced concrete,
block, brick, etc.
■ Specially designed carbide tip
geometry for increased penetration
■ Core body length: 4-1/4"
■ Usable drilling depth: 3-1/4"
■ From 1" to 4" diameter
1" ROTARY HAMMER with DUST COLLECTOR
Model HR2432
