Technical Specifications
GENERAL
Frequency Range ................................................
26.965-27.405 MHz
Frequency Control.............................................
Phase Lock Loop (PLL)
Channels ...............................................................
40
Modulation Type .................................................
AM
Antenna Connector ..........................................
SO-239
Antenna Impedance............................................
50 Ohm
PA Speaker ...........................................................
8-Ohm, 5 Watts
Microphone .........................................................
1000 ohm Electret
Power Supply ......................................................
13.8 VDC
Size .......................................................................
.10(D) x 2.25(H) x 7.25(W) in.
Unit Weight...........................................................
3 lbs.
RECEIVER
Sensitivity...............................................................
0.7 uV for 10dB s/n
Selectivity .............................................................
45 dB + 10 kHz
Squelch Range .....................................................
Adjustable less than 1 uV
Audio Output Power ........................................
4 Watts
Distortion at 1000 mV .....................................
3%
Audio Frequency Response ............................
400-2400 Hz
Intermediate Frequency ...................................
I° 10.695 MHz II° 455 kHz
Spurious Response ............................................
more than 45 dB
TRANSMITTER
RF Output Power ..............................................
4 Watts
Frequency Tolerance .........................................
0.005%
Harmonic Suppression .....................................
More than 60 dB
Modulation ..........................................................
AM 90%( ± 5%)›
WEATHER RECEIVER
Channel Frequency
Channel 1 162.400
Channel 2 162.425
Channel 3 162.450
Channel 4 162.475
Channel 5 162.500
Channel 6 162.525
Channel 7 162.550
Sensitivity at 12dB S/N .....................................
0.4 uV
Spurious Response ............................................
more than 45dB
Limited Warranty
Midland Radio Corporation will repair or
replace, at its option without charge, any Midland Citizen Band
transceiver which fails due to a defect in material or workman-
ship within Three Years following the initial consumer purchase.
This warranty does not apply to water damage, battery leak or
abuse. Accessories have a 90 day warranty from date of
purchase, including any antennas, chargers, or earphones. This
warranty does not include the cost of labor for removal or
re-installation of the product in a vehicle or other mounting.
For Product Purchased in the USA:
Performance of any obligation under this warranty may be
obtained by returning the warranted product, prepaid freight,
along with proof of purchase to:
Midland Radio Corporation
Warranty Service Department
5900 Parretta Drive
Kansas City, MO 64120
This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state. Note : The
above warranty applies only to merchandise purchased in the
United States of America or any of the territories or posses-
sions thereof, or from a U.S. Military exchange.
For Product Purchased in Canada:
Performance of any obligation under this warranty may be
obtained by returning the warranted product, along with proof
of purchase to your dealer in Canada. This warranty gives you
specified legal rights. Additional warranty rights may be
provided by law in some areas.
Limitation of Liability
MIDLAND’S RESPONSIBILITY IN CONNECTION WITH THIS
PRODUCT IS LIMITED TO REPAIR OR REPLACEMENT OF THE
PRODUCT, OR REFUND OF ITS PURCHASE PRICE, AT THE SOLE
DISCRETION OF MIDLAND. MIDLAND DISCLAIMS ANY AND ALL
WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR ANY PARTICULAR PURPOSE, AND NO OTHER
REMEDY SHALL BE AVAILABLE, INCLUDING, WITHOUT LIMITATION,
INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL
DAMAGES. IN NO EVENT SHALL MIDLAND’S LIABILITY EXCEED THE
PURCHASE PRICE OF THE PRODUCT AT ISSUE. SOME STATES DO
NOT PERMIT THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES AND, ACCORDINGLY,
THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU.
