9001z Features and Controls
Front Panel Controls
Backlit S/RF/
SWR Meter
Electret/Dynamic Mic
Selector Switch
S/RF/SWR/CAL
Selector Switch
NB/ANL OFF
Selector Switch
CB/WX Scan/ PA
Selector Switch
Bright/Dim
Selector Switch
CH9/ Norm/CH19
Selector Switch
XR Technology
On/OFF Switch
Channel LED
Readout
4-Pin Front Mic
Connector
Dual Knobs- ON/
OFF/ Volume and
Squelch
Dual Knobs-
XTRA Talk
Mic Gain and
RF Gain
Delta Tune Knob SWR Calibration
Knob
Guardian Alert
Knob
Channel Selector
Knob
Back Panel Controls
Antenna
Connector
PA Speaker
Jack
DC 13.8V
Power Jack
External
Speaker Jack
