Connecting Input Devices
A PC or notebook computer as well as video devices can be connected to the projector at the same
time. Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital
still cameras. Check the user manual of the connecting device to confirm it has the appropriate output
connector.
I
TEM
L
ABEL
D
ESCRIPTION
1
Audio-in
Connect an audio cable (not supplied) from the computer’s audio-out con-
nector.
Connect the supplied audio cable (mini jack-to-RCA x 2) from a video de-
vice.
2
RS-232
Reserved service port for firmware upgrades.
3
DVI-I
Connect the supplied DVI cable from a computer.
4
Video
Connect a composite video cable
(not supplied)
from a video device.
5
S-video
Connect the supplied S-video cable from a video device.
6
USB
Connect the supplied USB cable from a computer.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
