Marantz SR-18EX - Manual (Page 24)

ENGLISH
19
2. FUCTION SELECT & SURROUND MODE
When a function or surround mode button is selected:
VIDEO: Displays the current video source. When DSS/TV, LD,
DVD, VCR or AUX is selected with the function selector,
both AUDIO and VIDEO shows the same name.
AUDIO: Displays the current analog audio input source.
DIGITAL: Displays the current digital input source.
SURR-MODE: Displays the current Surround mode as follows;
AUTO, DOLBY, THX 5.1, THX Sur. EX , DTS CINEMA,
DTS MUSIC, HALL, MATRIX, MOVIE, 5-STEREO,
STEREO, MONO, S-DIRECT,
or 6CH-INPUT .
3. MASTER VOLUME CONTROL
Displayed when the MASTER volume is varied or a button of the
remote handset is pressed.
The box display indicates the 0 dB level with a solid box “ ”.
4. MUTE
When the MUTE button is pressed on the remote control, “MUTE” will
be shown on screen. Pressing MUTE button again will clear the
display, or adjust the volume.
5.SLEEP TIMER
When the SLEP button (D5) is pressed, the setting on or off and the
remaining time of the sleep timer function are displayed.
You can change the mode between on, off and the amount of time to
elapse before the unit will shut itself off by cycling the
SLEP button.
I O
U : D
D : D E
D
O I
L I A G T I
V
A
D
: D G – 5
D
V D
– S U R R M O D E : T
I
V
S C – I N E D
L L F E E V E L : 1 0 d B –
MA
A M S T E R V O U M E L
– – – – – – – – – – – – – – – – – – – –
M U T E
S L E E P T M E R I
O N 9 0 m i n
BASIC OPERATION
LISTENING TO THE TUNER
Frequency scan step for AM is selectable. Default is 10 kHz step. If
your country’s standard is 9 kHz step, prress “AM” button on the
remote more than 6 seconds. Scan step will change.
Note:
• Memory for the tuner will clear by this setup.
MANUAL TUNING
1. To select the tuner as the source, turn the INPUT SELECTOR knob
!5 on the front panel or press the TUNER button . on the remote.
2. Press the BAND button y on the SR-19EX or FM (D1)/ AM (D2)
button on page 1 at TUNER MODE on the remote to select the
desired frequency band if required.
3. Press the AUTO TUNING button !7 on the SR-19EX to display the
frequency.
4. Turn the GYRO TUNING knob @1 on SR-19EX or press or
button on the remote.
5. If FM is selected, press the FM MODE button u on the front panel
or the MODE button D5 on the remote to select the desired audio
mode.
AUTO TUNING (USING THE SR-19EX)
Light up the “AUTO TUNING” indicator by pressing the AUTO
TUNING button !7 and turn the GYRO TUNING knob @1.
AUTO TUNING (USING THE REMOTE CONTROL UNIT)
The or button is pressed for more than 1 second to start Auto
tuning function.
(FM) MODE Button Operation
When “AUTO” indicator is on in the display, FM stations which
broadcast in stereo will be received in stereo and the “STEREO”
indicator lights.
When “AUTO” indicator is off, all the FM stations will be received in
monaural regardless of whether or not they are broadcasting in
stereo.
PRESET TUNING
With this unit you can preset up to 50 FM/AM stations in any order.
For each station, you can memorize the frequency and reception
mode if desired.
1-a. Manual Presetting (Using the SR-19EX)
1. Refer to the “ MANUAL TUNING ” or “ AUTO TUNING ” section
above to tune in a desired station.
2. Press the MEMO button i. “PRESET - -” indicator starts blinking
on the display. While this is still blinking (approx. 5 seconds),
select the preset number by turning the
GYRO TUNING knob @1,
then press the MEMO button again.
3. When a number has been properly input, The display stops
blinking. The station is now stored in the specified preset memory
location.
1-b. Manual Presetting (Using the remote unit)
1. Tune in a desired station.
2. Press the M button ⁄3 of Tuner mode.
3. Enter the desired preset number with ten keypad ⁄2.
* When entering a single digit number (2, for example), either
input “02” or just input “2” and wait for a few seconds.
* If a number other than 1-50 is entered by mistake, that number
flashes in the display to indicate that it is invalid and the display
returns to the original frequency display.
