Monte Carlo Fan Company 5CY60XX - Manual (Page 4)

Install the switch housing using the 4
screws previously removed.
24
Remove 4 screws and save to install
switch housing.
23
Install switch housing plate by twist-
ing plate with key hole slots into
place. Replace screw removed and
tighten the 3 screws securely.
21
Connect plug from fan to switch
house plug.
22
Loosen 2 screws with key slots and
remove 1 screw without slot from
motor plate and save screw.
20
The screws, washers, and motor
pads are pre-installed to the blade
holders. Attach blade assembly to
motor and tighten screws securely.
19
