Monster, Step 9 rack mounting your powercenter – Monster Power HTS3000 User Manual
Page 25
21
Step 9
Rack Mounting Your PowerCenter
A) Remove two screws on the left fascia panel with a 3/32” allen key (not included).
Remove fascia panel and save it (if you wish to use the PowerCenter out of a rack in the future).
B) Line up the left rack “ear” over the two 3/32 holes on the left side of the PowerCenter.
Using the 3/32 Allen key, turn the two Allen screws provided clockwise until tight.
C) Repeat Step A for installation of rack ear on the right side of PowerCenter.
D) Align the HTS3000 on your equipment rack so that the slots in the “ears” line up
with the holes in the rack walls.
E) Secure the HTS3000 in place with four rack screws (not provided) until secure.
MONSTER
MONSTER
PO
PO
W
ER
ER
MONSTER
MONSTER
PO
PO
W
ER
ER
MONSTER
MONSTER
PO
PO
W
ER
ER
MONSTER
MONSTER
PO
PO
W
ER
ER
Home Theatre
Reference PowerCenter
HTS3000
SWITCHED OUTLETS
PO
W
ER
P
RO
TE
CT
ED
PROTECTION ON
OUTLETS
SY
ST
EM
G
RO
UN
DE
D
UN
SW
IT
CH
ED
O
N
SW
IT
CH
ED
O
N
TI
M
ED
O
N
O
N
O
FF
Attach RACK MOUNTS on the right and left side of the HTS3000 PowerCenter
