SPECIFICATIONS & FEATURES 2007 MX-5 MIATA
* Always wear your safety belt and deactivate passenger-side air bag when using any infant- or child-safety seat. † MX-5 Sport
requires Convenience Package, not available with Premium Package. ‡ SIRIUS Satellite Radio reception requires a subscription
and Mazda satellite radio receiver accessory kit. Available only in the U.S., except Alaska and Hawaii.
Product Changes and Options Availability: Following publication of this brochure, certain changes in standard equipment,
options, prices and the like, or product delays may have occurred which would not be included in these pages. Your Mazda
dealer is your best source for up-to-date information. Mazda reserves the right to change product specifications at any time
without incurring obligations. Options shown or described in this brochure are available at extra cost and may be offered only
in combination with other options or subject to additional ordering requirements or limitations.
MX-5 MIATA SPECIFIC ATIONS
SPECIFIC ATIONS
Engine size and type 2.0L MZR 4-cylinder; aluminum-alloy block and cylinder head
Valve gear DOHC 16-valve with variable intake-valve timing
Horsepower, SAE net 166 @ 6700 rpm
163 @ 6700 rpm (6-speed Sport AT)
Torque, SAE net lb-ft 140 @ 5000 rpm
Bore and stroke/compression ratio 3.44 x 3.27 inches/10.8:1
Ignition system/fuel system Distributorless electronic/multiport fuel injection
Fuel capacity/recommended fuel 12.7 U.S. gallons/premium unleaded gasoline
Steering ratio/turns, lock-to-lock 15.0:1/2.7
Turning circle, curb-to-curb 30.8 feet
Brakes 11.4-inch ventilated front discs;
11.0-inch solid rear discs
FUEL ECONOMY (EPA estimated mpg, city/hwy)
5-speed manual (SV, Sport) 25 city/30 hwy
6-speed manual (Touring, Grand Touring) 24 city/30 hwy
6-speed Sport AT automatic (Sport, Touring, Grand Touring) 22 city/30 hwy
CURB WEIGHTS MX-5 MX-5 Power Retractable Hard Top
5-speed manual (SV) 2441 lb –
5-speed manual (Sport) 2474 lb 2551 lb
6-speed manual (Touring, GT) 2498 lb 2573 lb
6-speed Sport AT automatic 2527 lb (Sport, Touring, GT) 2602 lb (Touring, GT)
DIMENSIONS & C APACITIES MX-5 MX-5 Power Retractable Hard Top
Wheelbase/overall length (in) 91.7/157.3 91.7/157.3
Overall width/height (in) 67.7/49.0 67.7/49.4
Track, front/rear (in) 58.7/58.9 58.7/58.9
Headroom/legroom/shoulder room (in) 37.4/43.1/53.2 37.0/43.1/53.2
Cargo volume (cu ft) 5.3 5.3
5-Speed 6-Speed 6-Speed Sport
TR ANSMISSION R ATIOS Manual Manual AT Automatic
1st gear 3.136 3.815 3.538
2nd gear 1.888 2.260 2.060
3rd gear 1.330 1.640 1.404
4th gear 1.000 1.177 1.000
5th gear 0.814 1.000 0.713
6th gear – 0.832 0.582
Final drive 4.100 4.100 4.100
MX-5 MIATA MECHANIC AL FEATURES
MX-5 Power
MECHANIC AL FEATURES MX-5 Retractable Hard Top
2.0L DOHC 16-valve 4-cylinder engine with variable valve timing S S
Aluminum alloy engine block and cylinder head S S
5-speed manual overdrive transmission with short-throw shifter S S
6-speed Sport AT automatic transmission with paddle shifters (Available except SV) (Available except Sport)
Aluminum Power Plant Frame (PPF) S S
Rack-and-pinion steering with engine-rpm-sensing variable assist S S
Power-assisted 4-wheel disc brakes S S
Anti-lock Brake System (ABS) with Electronic Brakeforce S S
Distribution (EBD)
Double-wishbone front suspension with aluminum control arms S S
Independent multilink rear suspension with aluminum S S
bearing support
Front and rear stabilizer bars; gas-charged shock absorbers S S
Sport-tuned exhaust system with dual outlets S S
MX-5 MIATA EQUIPMENT & FEATURES
MX-5 Power
EXTERIOR FEATURES MX-5 Retractable Hard Top
16-inch 5-spoke alloy wheels S S
P205/50R16 high-performance radial tires S S
Lightweight aluminum hood and trunk lid S S
Black-vinyl “Z-fold” convertible top with central release latch S –
Body-color power retractable hardtop – S
Black seatback bars and aero mesh screen S –
Silver seatback bars with aero mesh screen and air guide – S
Glass rear window with defogger S S
Dual body-color power remote mirrors S S
2-speed intermittent windshield wipers S S
Rear fender-mounted antenna S S
Clear-lens halogen headlights with projector-type low beams S S
Chrome outer door handles, headlight bezels and front grille surround – S
Halogen fog lights P S
MX-5 MIATA EQUIPMENT & FEATURES
MX-5 Power
INTERIOR FEATURES MX-5 Retractable Hard Top
Dual front air bags* with passenger-side deactivation switch S S
Side-impact air bags* S S
3-point lap/shoulder safety belts with pretensioners S S
Reclining bucket seats with integrated headrests; driver’s S S
seatback storage pocket
Black cloth upholstery and carpet floor mats S S
Rear open storage compartments (behind seats) S –
Lockable rear center console storage and glove compartment S S
Door-mounted bottle holders S S
Dual cup holders with covers S S
Power windows with driver’s one-touch-down feature S S
Passenger one-touch-down window feature P S
Power door locks P S
Remote trunk-lid and fuel-door release S S
Courtesy light on windshield header; ignition-keyhole light S S
White-on-black gauges with red nighttime illumination S S
Full instrumentation, including tachometer, coolant-temperature, S S
and oil-pressure gauges
3-spoke leather-wrapped (urethane on SV model) tilt steering wheel S S
Heater/defroster with multispeed blower and side-window demisters S S
CFC-free air conditioning (except SV model) S S
AM/FM/CD stereo with 4 speakers and digital clock S S
Steering-wheel-mounted audio controls P S
Engine-immobilizer antitheft system S S
Cruise control with steering-wheel-mounted controls P S
Remote keyless entry with retractable key P S
Floor tunnel net pocket P S
MX-5 MIATA OPTIONS & OPTION PACKAGES
OPTIONS & OPTION PACKAGES SV Sport Touring Grand Touring
Convenience Package (MX-5, standard on _ O S S
Power Retractable Hard Top): Power door
locks; remote keyless entry with retractable
key; silver seatback bars; fog lights; cruise
control; steering-wheel-mounted cruise and
audio controls; passenger one-touch-down
window; floor tunnel net pocket; covered
rear storage compartments (except PRHT)
Suspension Package: Sport-tuned _ _ O O
suspension; Bilstein ® shock absorbers;
limited-slip rear differential (manual
transmission only)
Premium Package #1 (MX-5 only, 6-speed _ _ _ O
manual without Suspension Package):
Xenon HID headlights; Dynamic Stability
Control (DSC) with Traction Control System;
limited-slip rear differential; Mazda Advanced
Keyless Entry System; antitheft alarm
Premium Package #2 (MX-5 and MX-5 Power _ _ _ O
Retractable Hard Top, 6-speed manual with
Suspension Package or 6-speed Sport AT):
Xenon HID headlights; Dynamic Stability
Control (DSC) with Traction Control System;
Mazda Advanced Keyless Entry System;
antitheft alarm
Appearance Package: Front and rear air O/A O/A O/A O/A
dam; side sill extensions
Interior Trim Package: Brushed-aluminum- O/A O/A O/A O/A
look instrument panel and door switch trim;
leather/aluminum gearshift knob
Run-flat tires with Tire-Pressure Monitoring – – O O
System (TPMS) (MX-5 only)
Front and rear splash guards (not available O/A O/A O/A O/A
with Appearance Package)
Rear lip spoiler (N/A PRHT) O/A O/A O/A O/A
Chrome fuel-filler door O/A O/A O/A O/A
In-dash 6-disc CD/MP3 changer O/A O/A O/A O/A
Perimeter alarm system with shock sensor †
_
O/A O/A O/A
Cargo net O/A O/A O/A O/A
Door-edge guards, color-keyed O/A O/A O/A O/A
All-weather floor mats O/A O/A O/A O/A
SIRIUS Satellite Radio ‡ receiver kit O/A O/A O/A O/A
Wheel locks O/A O/A O/A O/A
S: Standard P: Package O: Optional A: Dealer-available accessory –: Not available
TAN LEATHER BL ACK CLOTH BL ACK LEATHER 16 -INCH ALLOY 17-INCH ALLOY
UPHOLSTERY
COLOR & TRIM 2007 Mazda CX-7
WHEELS
COLOR COMBINATIONS
COLOR & TRIM 2007 MX-5 Miata
MODELS
SPORT (MX-5 Miata)
Includes all MX-5 Miata SV standard features plus:
• Air conditioning
• Leather-wrapped steering-wheel
TOURING (MX-5 Miata)
Includes the following features:
• 6-speed manual transmission
• Front shock tower brace
• 17-inch aluminum alloy wheels
• P205/45R17 high-performance tires
• Halogen fog lights
• Silver seatback bars
• Cruise control with steering-wheel-mounted controls
• Steering-wheel-mounted audio controls
• Power door locks
• Remote keyless entry with retractable key
• Covered rear storage compartments (behind seats)
• Floor tunnel net pocket
• 6-speaker sound system
• Leather-wrapped shift knob
• Passenger one-touch-down window
TOURING (MX-5 Miata Power Retractable Hard Top)
Includes the following features:
• 6-speed manual transmission
• Front shock tower brace
• 17-inch aluminum alloy wheels
• P205/45R17 high-performance tires
• 6-speaker sound system
• Leather-wrapped shift knob
GR AND TOURING (MX-5 Miata and MX-5 Miata Power
Retractable Hard Top)
Includes the following features in addition to or in place of MX-5 Miata Touring:
• Black- or tan-cloth convertible top (MX-5 Miata)
• Leather-trimmed heated seats
• 200-watt Bose ® 7-speaker audio system
with AudioPilot ® noise compensation
MX-5 MIATA MODEL AVAIL ABILIT Y
MODEL AVAILABILITY MX-5 Miata SV MX-5 Miata Sport MX-5 Miata Touring MX-5 Miata Grand Touring
MX-5 T T T T
MX-5 Power Retractable Hard Top – T T T
SUNLIGHT SILVER METALLIC
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata Sport, Touring Black Cloth
MX-5 Miata Grand Touring Black Leather
COPPER RED MIC A
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata Sport, Touring Black Cloth
MX-5 Miata Grand Touring Tan Leather
HIGHL AND GREEN
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata Sport, Touring Black Cloth
MX-5 Miata Grand Touring Tan Leather
STORMY BLUE MIC A
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata Sport, Touring Black Cloth
MX-5 Miata Grand Touring Black or Tan Leather
BRILLIANT BL ACK CLEARCOAT
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata Sport, Touring Black Cloth
MX-5 Miata Grand Touring Tan Leather
TRUE RED
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata SV, Sport, Touring Black Cloth
MX-5 Miata Grand Touring Black Leather
GALAXY GRAY MICA
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata Sport, Touring Black Cloth
MX-5 Miata Grand Touring Black or Tan Leather
* Not available on Power Retractable Hard Top model.
MARBLE WHITE*
TRIM LEVEL INTERIOR FABRICS
MX-5 Miata SV, Sport, Touring Black Cloth
MX-5 Miata Grand Touring Tan Leather
