Chapter 3 – Related MultiVOIP Setup Parameters
52 Multi-Tech Systems, Inc. Avaya Communication Manager Guide
Click on the Memory Setting button to access the Memory screen. The configurable fields must be
configured as shown below.
GK General Settings Definitions
(cont’d)
Field Name Values Description
GK Memory Values
Maximum
Calls 10, 20, 30 The maximum number of concurrent calls. MVP210AV support 5 calls;
MVP410 AV supports 10 calls; MVP810 AV supports 15 calls.
Maximum
Registrations
2 - 250 Maximum number of endpoints that can be registered on the
gatekeeper-controlled network.
Note: IP phones registrations are limited to 15 regardless of this
setting.
RAS Parameters In H.323, RAS parameters pertain to Registration, Admission, and
Status in the H.225 Call Signaling Protocol.
Response
TO
The timeout (in seconds) before re-transmission of a RAS message that
had previously fetched no response.
RAS Port The RAS port for gatekeeper communication with endpoints.
Default value = 1719
Q.931 Parameters
In H.323, Q.931 parameters are those that pertain to the set-up and
tear- down of connections between H.323 endpoints.
Response
TO (sec)
The timeout (in seconds) waiting for the TCP reply.
Connect TO
(sec)
The timeout (in seconds) waiting for the Connect message of a call.
Q.931
Signaling
Port
Logical port through which Q.931 protocol messages are handled.
Default value = 1730
Buttons
Default Invokes default values for all parameters on the GK General Settings
screen.
