Chapter 3 – Related MultiVOIP Setup Parameters
Multi-Tech Systems, Inc. Avaya Communication Manager Guide 37
Note that Voice/FAX parameters are applied on a channel-by-channel basis. However, once you have
established a set of Voice/FAX parameters for a particular channel, you can apply this entire set of
Voice/FAX parameters to another channel by using the Copy Channel button and its dialog box. To copy
a set of Voice/FAX parameters to all channels, select “Copy to All” and click Copy.
The Voice/FAX Parameters fields are described in the tables below.
Voice/Fax Parameter Definitions
Field Name Values Description
Default -- When this button is clicked, all Voice/FAX parameters
are set to their default values.
Select
Channel
1-2 (210) 1-4 (410)
1-8 (810) Channel to be configured is selected here.
Copy
Channel
-- Copies the Voice/FAX attributes of one channel to
another channel. Attributes can be copied to multiple
channels or all channels at once.
Voice Gain -- Signal amplification (or attenuation) in dB.
Input Gain +31dB to –31dB Modifies audio level entering voice channel before it is
sent over the network to the remote VOIP. The default &
recommended value is 0 dB.
Output Gain +31dB to –31dB Modifies audio level being output to the device attached
to the voice channel. The default and recommended
value is 0 dB.
