Metra Electronics MAZDA CX7 2007-09 99-7508 - Manual (Page 5)

99-7508 KIT ASSEMBLY
3
A
B
C
DIN RADIO PROVISION WITH POCKET
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward. (Figure A) 1
Slide the aftermarket radio into the DIN
cage until it snaps into place. (Figure B) 2
Snap the pocket into the radio housing.
(Figure C) 3
Continue to final assembly.
* Note: Refer also to the instructions included with the aftermarket radio.
