Magnadyne MV-IPAD2 - Manual (Page 3)

3
Docking Station Functions
1. FM Transmitter Adjustment Button: Push the (-)
button to tune to a lower radio frequency, press the
(+) button to tune to a higher radio frequency.
2. FM Transmitter LCD Display: Displays the audio
transmission frequency.
3. Dome Light Button: Press to turn on or off the
dome lights.
4. IPAD Docking Housing Release Button: To release
the docking housing, push the button then gently
pull down the housing. Adjust the housing to the
desired viewing position.
5. Power Button: Press this button to turn the docking
station on or off.
6. Dome Lights.
7. IR Repeater: The audio signal is converted to an
infrared light and transmitted to the headphones.
8. IPAD Docking Housing Access Door: See the instal-
lation part of this manual for more information.
9. IPAD Eject Button: See the installation part of this
manual for more information.
10. IPAD Sleep/Wake Button: Press this button to
activate the IPAD’s sleep/wake button.
3
4
5
2
1
7
6
9
10
8
