Magnadyne MV-IPAD2 - Manual (Page 11)

11
Installation
Specification
The MV-IPAD must be mounted using a universal
shroud/bracket system (purchased separately).
1. Using the screws provided with the universal
shroud/bracket system attach the MV-IPAD docking
system to the universal shroud.
2. Refer to the instructions included with the shroud/
bracket system on how to mount the bracket.
Warning: Take extra care not to penetrate the roof of
your vehicle during installation.
3. Using the screws provided with the universal
shroud/bracket system attach the docking station/
shroud assembly to the bracket.
FM Transmitter Frequency Range: 87.5 – 107.9 MHz
Operating Voltage: 10.5-14.5V DC
Operating Temperature: 0-60 Degrees C
Current Consumption: 2A Maximum
IR Transmitter Frequency: 2.8 MHz (Right)/2.3 MHz (Left)
