102
Mounting the mecablitz
Montaggio del mecablitz
Montaje del mecablitz
3. Mounting the mecablitz
3.1 Mounting the mecablitz on the camera
Turn off the camera and the mecablitz by their main
switch.
mecablitz 36 AF-3 C and 36 AF-3 N
• Turn the knurled nut against the mecablitz housing until the
stop point is reached.
• Slide the mecablitz foot completely into the camera’s acces-
sory shoe.
• Turn the knurled nut against the camera body as far as
possible, thereby clamping the mecablitz.
mecablitz 36 AF-3 M
• Slide the mecablitz foot completely into the camera’s acces-
sory shoe.
• Lightly press the unlatching button “PUSH” upward to
clamp the mecablitz in the camera’s accessory shoe.
☞
