Instructions For Use. Page 8

A1001

SPECIFICATIONS

Musical Fidelity reserves the right to make improvements which may result in feature or

specification changes without notice.

A1001 CLASS A SUPER INTEGRATED AMPLIFIER

Power output

200W RMS per channel into 8

400W RMS per channel into 4

Frequency response

10 Hz - 30kHz + 1dB

THD

< 0.06% 20Hz - 20kHz to full rated power
< 0.003% @ 1kHz to full rated power

S/N ratio

> -91dB unweighted
> -96dB ‘A’ weighted

Inputs

6 x Line level

Input sensitivity

300mV

Power consumption

1000W (maximum)

Power requirement

100/115/230V AC 50/60Hz
(Factory preset for country)

Dimensions

475 x 164 x 540mm (W x H x D)
Height includes feet, depth includes
terminals and volume knob

Weight

30 kgs

Standard accesories

1 x IEC type mains lead
1 x A1001 remote control handset
2 x batteries (AA, LR6, AM6)

A1001-97-1
