Instructions For Use. Page 3
A1001
BACK PANEL
7
Right speaker outputs
8
CD input
9
Tuner input
10
Aux 1 input
11
Aux 2 input
12
Aux 3 input
13
Tape input
14
Tape record output
15
Preamp output
16
Left speaker outputs
17
Right preamp & power amp link
18
Left preamp & power amp link
19
IEC type mains inlet
FRONT PANEL
1
Power (on / off) button
2
Tape / source select (tape
monitor) button
3
Volume control
4
Volume position & mute LED
5
Source selector buttons
6
Remote receiver lens
1
2
4
5
6
3
7
8 9 10 11 12 13 14 15
16
17
18
19
CONNECTIONS AND FACILITIES
