Martin Audio AQ6 - Manual (Page 5)

AQ6
Ultra-compact, full-range system
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: [email protected]
All information is Copyright © 2005 Martin Audio Ltd.
www.martin-audio.com
5 of 5
architectual
architectural and engineering specifications
The loudspeaker system shall be of the two-way passive
type consisting of one 6.5" (165mm) direct radiating
reflex loaded low frequency transducer and one 1"
(25mm) horn loaded dome tweeter in a structural
foamed ABS trapezoidal enclosure. The enclosure shall
be fitted with threaded inserts for attachment to a
custom bracket. An internal 3.5kHz passive crossover
network shall integrate the low and high frequency
sections.
Performance of the loudspeaker system with its
electronic controller shall meet or exceed the following
criteria:
Frequency response measured 1 metre on axis shall be
80Hz-20kHz ±3dB.
High frequency dispersion at -6dB points shall be 90˚H
x 90˚V.
Power handling shall be 100W AES, 400W peak.
Rated impedance shall be 8 ohms.
Maximum SPL measured at 1 metre on axis shall be
108dB continuous, 114dB peak.
Dimensions (W) 207mm x (H) 316mm x (D) 207mm
(8.2ins x 12.5ins x 8.2ins).
Weight 6kg (13.2lbs).
The loudspeaker system shall be the Martin Audio AQ6.
Notes
(1) Measured on-axis in half space at 2 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in half space at 2 metres with 1 watt input, using band limited pink noise, then referred to 1 metre.
(4) Measured in half space at 2 metres using band limited pink noise, then referred to 1 metre.
(5) Measured on-axis in open (4
π) space at 2 metres, then referred to 1 metre.
(6) Measured in open (4 π) space at 2 metres with 1 watt input, using band limited pink noise, then referred to 1 metre.
(7) Measured in open (4 π) space at 2 metres using band limited pink noise, then referred to 1 metre.
TTrr aa dd ee DD ee ss cc rr ii pp tt ii oo nn ss AA cc tt
Due to Martin Audio’s policy of continuing improvement, we reserve the right to alter these specifications without prior notice.
Martin Audio is committed to refining state of the art sound reinforcement, combining in-depth product and field applications
research with advanced manufacturing techniques. Every Martin Audio product is built to the highest manufacturing standards
and rigorously tested to ensure that it meets the performance criteria specified in the design.
technical specifications
TYPE Ultra-compact, two-way passive,
vented trapezoid
FREQUENCY RESPONSE (5) 80Hz-20kHz ± 3dB
DRIVERS
6.5" (165mm) bass driver
1" (25mm) horn loaded dome tweeter
RATED POWER (2) 100W AES, 400W peak
RECOMMENDED 100-200W into 4 ohms
AMPLIFIER
SENSITIVITY (6)
90dB
MAXIMUM SPL (7) 108dB continuous, 114dB peak
NOMINAL IMPEDANCE 8 ohms
DISPERSION (-6dB) 90º horizontal, 90º vertical
CROSSOVER 3.5kHz passive
ENCLOSURE 9 litre, structural foamed ABS
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 12 amp push-lock
FITTINGS 4 x M6 inserts for bracket
1 x M6 insert for safety point
OPTIONS 30W 100/70V line transformer
DIMENSIONS (W) 207mm x (H) 316mm x (D) 207mm
(W) 8.2ins x (H) 12.5ins x (D) 8.2ins
WEIGHT 6kg (13.2lbs)
accessories
AQWB6 Wall Bracket
AQCB6 Ceiling Bracket
