21
ENGLISH
Specification of RGB signals in each computer mode of the projector
Signal mode resolution horizontal Vertical Normal Native
(H x V) frequency (kHz) frequency (Hz) (H x V) (H x V)
TV60 – 15.73 59.94 1024 x 768 640 x 438
TV50 – 15.63 50.00 1024 x 768 680 x 544
HDTV – 33.75 60.00 1024 x 576 (882 x 496)
PC98 640 x 400 24.82 56.42 1024 x 640 640 x 400
CGA70 640 x 400 31.47 70.09 1024 x 640 640 x 400
CGA84 640 x 400 37.86 84.13 1024 x 640 640 x 400
CGA85 640 x 400 37.86 85.08 1024 x 640 640 x 400
VGA60 640 x 480 31.47 59.94 1024 x 768 640 x 480
VGA72 640 x 480 37.86 72.81 1024 x 768 640 x 480
VGA75 640 x 480 37.50 75.00 1024 x 768 640 x 480
VGA85 640 x 480 43.27 85.01 1024 x 768 640 x 480
SVGA56 800 x 600 35.16 56.25 1024 x 768 800 x 600
SVGA60 800 x 600 37.88 60.32 1024 x 768 800 x 600
SVGA72 800 x 600 48.08 72.19 1024 x 768 800 x 600
SVGA75 800 x 600 46.88 75.00 1024 x 768 800 x 600
SVGA85 800 x 600 53.67 85.06 1024 x 768 800 x 600
XGA43i 1024 x 768 35.52 86.96 1024 x 768 1024 x 768
XGA60 1024 x 768 48.36 60.00 1024 x 768 1024 x 768
XGA70 1024 x 768 56.48 70.07 1024 x 768 1024 x 768
XGA75 1024 x 768 60.02 75.03 1024 x 768 1024 x 768
XGA85 1024 x 768 68.68 85.00 1024 x 768 1024 x 768
SXGA70a 1152 x 864 63.85 70.01 1024 x 768 1024 x 768
SXGA75a 1152 x 864 67.50 75.00 1024 x 768 1024 x 768
SXGA85a 1152 x 864 77.49 85.06 1024 x 768 1024 x 768
SXGA60a 1280 x 960 60.00 60.00 1024 x 768 1024 x 768
SXGA75a 1280 x 960 75.00 75.00 1024 x 768 1024 x 768
SXGA43i 1280 x 1024 46.43 86.87 960 x 768 1024 x 768
SXGA60 1280 x 1024 63.98 60.02 960 x 768 1024 x 768
SXGA75 1280 x 1024 79.98 75.03 960 x 768 1024 x 768
SXGA85 1280 x 1024 91.15 85.02 960 x 768 –
UXGA48i 1600 x 1200 62.50 96.08 1024 x 768 –
UXGA60 1600 x 1200 75.00 60.00 1024 x 768 –
UXGA65 1600 x 1200 81.25 65.00 1024 x 768 –
UXGA70 1600 x 1200 87.50 70.00 1024 x 768 –
UXGA75 1600 x 1200 93.75 75.00 1024 x 768 –
UXGA80 1600 x 1200 100.00 80.00 1024 x 768 –
UXGA85 1600 x 1200 106.25 85.00 1024 x 768 –
MAC13 640 x 480 35.00 66.67 1024 x 768 640 x 480
MAC16 832 x 624 49.72 74.55 1024 x 768 832 x 624
MAC19 1024 x 768 60.24 75.02 1024 x 768 1024 x 768
MAC21 1152 x 870 68.59 74.96 1024 x 768 1024 x 768
HP75 1024 x 768 62.94 74.92 1024 x 768 1024 x 768
HP72 1280 x 1024 78.13 72.00 960 x 768 1024 x 768
SUN66a 1152 x 900 61.85 66.00 984 x 768 1024 x 768
SUN76a 1152 x 900 71.81 76.63 984 x 768 1024 x 768
SUN66 1280 x 1024 71.68 66.68 960 x 768 1024 x 768
SUN76 1280 x 1024 81.13 76.11 960 x 768 1024 x 768
SGI72 1280 x 1024 76.92 72.30 960 x 768 1024 x 768
SGI76 1280 x 1024 82.00 76.00 960 x 768 1024 x 768
IBM60 1280 x 1024 63.42 60.00 960 x 768 1024 x 768
• *1 : As a result of line reduction in the projection
process with the computer models listed above, lines
and portions of characters found in the original data
may be missing from the projected image.
• When the ZOOM MODE of PRESENTATION menu is set
to 4, by pressing the EXPAND button on the remote con-
trol, it will switch to the screen displaying the picture as
its original size (real screen display). In the real screen
display, pictures will be black-framed when picture reso-
lution is lower than 1,024 ✕ 768.
Important:
•
Some computers may not be compatible with the projector.
• The projector's maximum resolution is 1,024 ✕ 768 pixel.
It may not be displayed correctly for the pictures of higher
resolutions than 1,024 ✕ 768.
• The picture with a SYNC on G (Green) signal may
jitter.
• The picture with a SYNC on G (Green) signal may be
tinged with green.
• If the resolution and frequency of your computer are not
shown on the table., change the resolution of your com-
puter. You may find the compatible resolution and fre-
quency.
• Set the RGB/Y, C B , C R in SIGNAL menu to RGB, when
inputting the HDTV signal as RGB signal.
