13
ENGLISH
Projector + IBM PC or IBM PC compatibles
Make sure that your equipment is turned off before connection.
Important:
• Connectors or analog RGB output adapters may be necessary depending on the personal computer connected to
this projector. Please contact your dealer.
• The audio input for a personal computer is the stereo mini-jack. There are some personal computers that have
different types of audio outputs or none at all. Please ask your dealer for details.
• For connection details, refer to the owner's guide of each component.
to monitor
port
to monitor port
desktop computer
notebook computer
RGB cable for PC
PC audio
cable (option)
to PC audio
output
to RGB IN
to LINE IN
When outputting to both a PC monitor and the projector
to monitor
port
desktop computer
PC audio
cable (option)
RGB cable for PC
RGB cable
(option)
to LINE IN
to PC audio
output
to PC
monitor
to RGB IN
to RGB OUT
