Iplmcc1635apg2.pdf, 35cc gas chain saw, Mcc1635a – McCulloch MCC1435A User Manual
Page 35: Parts list
35cc Gas Chain Saw
6/12/2009
No.
Parts No.
Description
Q
P Code
1
9SGEB-05-20
SCREW
4
110
2
9SKKB-04-10
SCREW
7
110
3
9067-310802
CAP
1
110
4
9014-310803
GASKET
1
110
5
9292-311001F
自
CYLINDER
1
110
6
9067-310801
CAP
1
110
7
9014-310801
GASKET
1
110
8
9189-311001
PISTON RING
2
110
9
9290-311002
PISTON
1
110
10
9CA-10.3
RING
1
110
11
9131-310801
WASHER
1
110
12
9NR-K101411
ROLLER
1
110
13
9PC-10-32
PIN, PISTON
1
110
14
9157-332101
SEAL
1
110
15
9228-310819
自
CLY CASE ASS'Y
1
110
15-1
9072-310802F
CLY CASE, LEFT
1
110
15-2
9PA-03-08S
PIN 3
110
15-3
9072-310801F
CLY CASE, RIGHT
1
110
15-4
9SKKB-05-27
SCREW
4
110
16
9DB-620101
BEARING
2
110
MCC1635A
PARTS LIST
17
9228-310801-A
CRANK/ROD ASS'Y
1
110
18
9014-310802
GASKET
1
110
19
9CB-32
RING
1
110
20
9157-310801
SEAL
1
110
21
9059-311001
BEARING
1
110
22
9191-310802
SCREW
2
110
23
9010-311002
WIRE
1
110
24
9NCC-05U
NUT
2
110
25
9SKKB-05-14
SCREW
2
110
26A
AO9014-310810-US888
KIT SPARK ARRESTOR ( 26 & 27)
1
110
26
9014-310810 COVER,
MESH
1
110
27
9016-310801 SPARK
ARRESTER
1
110
28
9228-311005T
MUFFLER ASS'Y
1
110
29
9014-310804
GASKET
1
110
30
9191-310803
SCREW
2
110
31
9010-311003
WIRE
1
110
32
9SKKB-04-14
SCREW
6
110
33
9288-310801
IGNITION ASS'Y
1
110
34
9NHC-08
NUT
1
110
35
9169-310801
FLYWHEEL ASS'Y
1
110
36
6221-830301
WOODRUFF KEY
1
110
37
9014-310805
GASKET
1
110
PARTS LIST
